System And Components
481-6696 CONTROL GP-ELECTRONICS/N NMA1-UP
Group No: 481-6696
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9636 | 1 FUSE (30-AMPERE) | 7 | |
| 9W1446 | 2 FUSE (20-AMPERE) | 6 | |
| 9W1441 | 3 FUSE (15-AMPERE) | 11 | |
| 9W1442 | 4 FUSE (10-AMPERE) | 25 | |
| 2748268 | 5 FUSE (7.5-AMPERE) | 2 | |
| 1395345 | 6 FUSE (5-AMPERE) | 3 | |
| 3E6477 | 8 RELAY AS (24-VOLT)(WORK LIGHTS) | 4 | |
| 3E6477 | 8A RELAY AS (24-VOLT)(TRAVEL LIGHT) | 1 | |
| 3E6477 | 8B RELAY AS (24-VOLT)(SPARE) | 2 | |
| 3E6477 | 8C RELAY AS (24-VOLT)(BEACON LIGHT) | 1 | |
| 8T0328 | 9 WASHER-HARD (5.5X10X1-MM THK) | 12 | |
| 3T0851 | 10 LOCKNUT (M5X0.8-THD) | 12 | |
| 9X6153 | 11 BOLT (M6X1X10-MM) | 4 | |
| 9X8267 | 12 WASHER (6.6X12X2-MM THK) | 8 | |
| 2119347 | 13 WASHER-SPRING | 8 | |
| 2418368 | 14 SWITCH GP-MAGNETIC (24-VOLT)(MAIN POWER) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T0269 | 15 BOLT-SOCKET HEAD (M6X1X20-MM) | 4 | |
| 6V8225 | 16 NUT (M6X1-THD) | 4 | |
| 6V5215 | 17 BOLT (M8X1.25X16-MM) | 2 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 3B4505 | 19 LOCKWASHER | 6 | |
| 2643613 | 20 WASHER (3.7X7X.5-MM THK) | 7 | |
| 3C6969 | 21 NUT (M3X0.5-THD) | 7 | |
| 2207087 | 22 FUSE (125-AMPERE) | 1 | |
| 5P7970 | 23 NUT (M8X1.25-THD) | 4 | |
| 5122228 | 24 PLATE-PROTECTION | 1 | |
| 5122227 | 25 MOUNT-ISOLATION | 12 | |
| 1622165 | 26 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 4 | |
| 3B4501 | 27 LOCKWASHER | 8 | |
| 5W5038 | 28 WASHER (4.3X9X0.8-MM THK) | 4 | |
| 5122226 | 29 NUT-SPACER (M4X0.7-THD) | 4 | |
| 1P7326 | 30 WASHER (4.32X9.52X1.52-MM THK) | 4 | |
| 4390578 | 31 BOLT (M4X0.7X8-MM) | 4 | |
| 5122225 | 32 SPACER | 3 | |
| 2486981 | 33 SCREW-MACHINE (M3X0.5X22-MM) | 4 | |
| 9B1117 | 34 LOCKWASHER | 3 | |
| 5195016 | 35 MODULE-CONTROL | 1 | |
| 4569585 | 36 FUSE (80-AMPERE) | 1 | |
| 1613128 | 37 RELAY (24-VOLT)(BACKUP ALARM) | 1 | |
| 1613128 | 38 RELAY (24-VOLT)(SPARE) | 13 | |
| 1613128 | 39 RELAY (24-VOLT)(ACTION ALARM) | 1 | |
| 1613128 | 40 RELAY (24-VOLT)(HAZARD LIGHT) | 1 | |
| 1613128 | 41 RELAY (24-VOLT)(CONVEYOR RAISE) | 1 | |
| 1613128 | 42 RELAY (24-VOLT)(CONVEYOR SWING RIGHT) | 1 | |
| 1613128 | 43 RELAY (24-VOLT)(DUST ABATEMENT) | 1 | |
| 1613128 | 44 RELAY (24-VOLT)(HIGH PRESSURE WASH) | 1 | |
| 1613128 | 45 RELAY (24-VOLT)(CONVEYOR LOWER) | 1 | |
| 1613128 | 46 RELAY (24-VOLT)(CONVEYOR SWING LEFT) | 1 | |
| 1613128 | 47 RELAY (24-VOLT)(ANTISLAB FLOAT) | 1 | |
| 1613128 | 48 RELAY (24-VOLT)(APU MOTOR DISABLE) | 1 | |
| 1613128 | 49 RELAY (24-VOLT)(RIGHT SIDE PLATE LIGHT) | 1 | |
| 1613128 | 50 RELAY (24-VOLT)(TRUCK SIGNAL GREEN) | 1 | |
| 1613128 | 51 RELAY (24-VOLT)(TRUCK SIGNAL RED) | 1 | |
| 1613128 | 52 RELAY (24-VOLT)(CONVEYOR FOLD UP) | 1 | |
| 1613128 | 53 RELAY (24-VOLT)(STARTER) | 1 | |
| 1613128 | 54 RELAY (24-VOLT)(CANOPY LOWER) | 1 | |
| 1613128 | 55 RELAY (24-VOLT)(ANTISLAB LOWER) | 1 | |
| 1613128 | 56 RELAY (24-VOLT)(CONVEYOR FOLD DOWN) | 1 | |
| 1613128 | 57 RELAY (24-VOLT)(ANTISLAB RAISE) | 1 | |
| 1613128 | 58 RELAY (24-VOLT)(CANOPY RAISE) | 1 | |
| 1613128 | 59 RELAY (24-VOLT)(WATER SYSTEM ON) | 1 | |
| 1613128 | 60 RELAY (24-VOLT)(LEFT SIDE PLATE LIGHT) | 1 | |
| 1613128 | 61 RELAY (24-VOLT)(RIGHT TURN SIGNAL) | 1 | |
| 1613128 | 62 RELAY (24-VOLT)(LEFT TURN SIGNAL) | 1 | |
| 1613128 | 63 RELAY (24-VOLT)(TRUCK HORN) | 1 | |
| 1613128 | 64 RELAY (24-VOLT)(WALKWAY, TAIL LIGHT) | 1 | |
| 1613128 | 65 RELAY (24-VOLT)(BRAKE LIGHT) | 1 |
