System And Components
381-6619 SEAT & MOUNTING GPS/N NMA1-UP
Group No: 381-6619
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2874 | 1 NUT (M5X0.8-THD) | 4 | |
| 6R7943 | 2 SCREW (M5X0.8X15-MM) | 16 | |
| 7X7729 | 3 WASHER (11X25X3-MM THK) | 4 | |
| 8T0328 | 4 WASHER-HARD (5.5X10X1-MM THK) | 16 | |
| 8T4189 | 5 BOLT (M8X1.25X20-MM) | 5 | |
| 8T4195 | 6 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4224 | 7 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 1272170 | 8 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 2 | |
| 2225151 | 9 PAWL | 1 | |
| 2869963 | 10 LATCH AS | 1 | |
| 2987788 | 11 BUMPER | 2 | |
| 4831858 | 12 RAIL AS | 2 | |
| 4831915 | 13 BASE AS-SEAT | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4833167 | 14 PLATE | 1 | |
| 5398940 | 15 PIN AS | 1 | |
| 5419435 | 16 SEAT GP-SUSPENSION | 1 | |
| 5434504 | 17 DOOR AS | 1 | |
| 1533723 | 17A HINGE AS | 2 | |
| 8T5447 | RING-RETAINING | 1 | |
| 5434505 | 18 BASE AS-SEAT | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 5 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 12 | |
| 8T0325 | 19 BOLT (M5X0.8X14-MM) | 12 | |
| 5P5649 | 20 SEAL-BULK (0.3-M EACH) | ||
| 5P5649 | 20A SEAL-BULK (0.4-M EACH) |
