System And Components
487-8409 TANK GP-FUELS/N KWA1-UP
Group No: 487-8409
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9P7121 | 1 STRAINER-FUEL | 1 | |
| 2977999 | 2 ELBOW AS | 1 | |
| 8T2530 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3289050 | 3 SENSOR AS-LIQUID LEVEL (FUEL) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 2304014 | RECEPTACLE AS-CONNECTOR (3-PIN) | 2 | |
| 3634123 | GASKET | 2 | |
| 3302172 | 4 FITTING-FUEL (WITH FILTER) | 1 | |
| 3577399 | 5 CAP GP-FUEL FILLER | 1 | |
| 3497059 | CAP AS-FUEL (LOCKABLE, VENTED) | 1 | |
| 3507735 | KIT-CAP FILTER (FUEL TANK) | 1 | |
| 3641995 | BOOT-FUEL CAP | 1 | |
| 3726950 | 6 TANK-FUEL | 1 | |
| 4491398 | 7 ADAPTER AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 1608754 | 8 BOLT (M5X0.8X40-MM) | 5 | |
| 2385080 | 9 SEAL-O-RING | 1 | |
| 3068127 | 10 ADAPTER | 1 | |
| 3510283 | 11 VALVE AS-SHUTOFF (FUEL) | 1 | |
| 6V7238 | VALVE-SHUTOFF | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 8T0328 | 12 WASHER-HARD (5.5X10X1-MM THK) | 5 |
