Assembly
100%

463-6494 DOOR GP-ACCESS -LHS/N KWA1-UP

Group No: 463-6494
Part NumberPart NameQty
8T41951 BOLT (M10X1.5X30-MM)16
8T41962 BOLT (M10X1.5X35-MM)1
8T41893 BOLT (M8X1.25X20-MM)35
8T49084 BOLT (M8X1.25X25-MM)14
3B46175 PIN-COTTER1
5P41166 WASHER-HARD (8.8X20.5X2-MM THK)16
5T92937 LATCH-MAGNETIC3
6I05938 BOLT (M10X1.5X30-MM)1
7X77299 WASHER (11X25X3-MM THK)10
8T038910 LOCKNUT (M10X1.5-THD)2
8T412111 WASHER-HARD (11X21X2.5-MM THK)6
8T413812 BOLT (M6X1X20-MM)4
8T418013 SCREW-MACHINE (M5X0.8X20-MM)4
8T422314 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422415 WASHER-HARD (8.8X16X2-MM THK)33
8T474716 BRACKET2
8Y637717 STRIKER1
9X825618 WASHER (6.6X12X2-MM THK)4
111020419 PLATE AS1
111177720 BUMPER-RUBBER2
112152821 HANDLE AS1
8Y4501SPRING-HANDLE1
256766922 PLATE7
305316923 PAWL1
326061024 LATCH AS1
1H3244LOCKWASHER4
0966331NUT (M12X1.75-THD)2
3445673NUT (M6X1-THD)4
3260612WASHER-TAB2
333645925 BRACKET1
398304626 PLATE3
463654527 PANEL1
476208128 FRAME AS1
8T3490NUT-WELD (M10X1.5-THD)6
8T3612NUT-WELD (M8X1.25-THD)1
476208729 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)3
8T3612NUT-WELD (M8X1.25-THD)2
476210230 BRACKET AS1
489822831 HINGE AS7
521550332 BRACKET1
521551833 COVER1
521589534 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)2
521600235 PANEL AS-DOOR1
521760636 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)2
532701437 ROD-PROP1
542646138 DOOR AS1
544281439 DOOR AS1
564478740 PLATE-LOCK1
108431141 SCREW-MACHINE (3/8-16X0.75-IN)1
9G275942 LATCH AS-DOOR1
562735843 SHIM (2-MM THK)3
