System And Components
387-3204 BUMPER GP-REARS/N TPH1-299
Group No: 387-3204
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1111777 | 1 BUMPER-RUBBER | 4 | |
| 2567669 | 2 PLATE | 3 | |
| 4898228 | 4 HINGE AS | 3 | |
| 3053169 | 5 PAWL | 1 | |
| 3260610 | 6 LATCH AS | 1 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0966331 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 5399232 | 7 PLATE | 1 | |
| 5399231 | 8 BUMPER AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 25 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 8 | |
| 3558941 | NUT-WELD (M16X2-THD) | 4 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 8T4183 | 10 BOLT (M12X1.75X40-MM) | 13 | |
| 8T4223 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 13 | |
| 8T4908 | 12 BOLT (M8X1.25X25-MM) | 12 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 6 |
