System And Components
354-7997 LINES GP-OILS/N RDY1-UP
Group No: 354-7997
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 1 | |
| 3428949 | 2 VALVE | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3511780 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3548041 | 4 TUBE AS-OIL | 1 | |
| 3561213 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 0S0509 | 6 BOLT (3/8-16X0.75-IN) | 1 | |
| 1A4273 | 7 BOLT (5/8-18X1.25-IN) | 1 | |
| 3491209 | 8 CLIP | 1 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P8247 | 10 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 5S0003 | 11 NUT (5/16-18-THD) | 1 | |
| 1091145 | 12 CLAMP-HOSE | 4 | |
| 6V4248 | 13 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5839 | 14 WASHER (11X21X2.5-MM THK) | 1 | |
| 8M0547 | 15 ELBOW-FLARED (SWIVEL) | 1 | |
| 8T1887 | 16 CLIP (SLOT) | 1 | |
| 8T1888 | 17 CLIP (TAB) | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 5P1505 | 19 HOSE (45-CM) | ||
| 5P1505 | 19A HOSE (35-CM) |
