System And Components
496-4987 AIR CLEANER GPS/N EE21-UP
Group No: 496-4987
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4195 | 1 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4908 | 2 BOLT (M8X1.25X25-MM) | 10 | |
| 5P1076 | 3 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 7X0579 | 4 WASHER-HARD (8.8X25.5X2-MM THK) | 10 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4956 | 6 BOLT (M12X1.75X35-MM) | 4 | |
| 9Y6102 | 7 ELBOW | 2 | |
| 1196298 | 8 CLAMP AS | 4 | |
| 7S7816 | LOCKNUT | 1 | |
| 1488312 | 9 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3T4965 | ADAPTER | 1 | |
| 2540816 | 10 CLAMP | 1 | |
| 3510261 | 11 ELBOW AS | 1 | |
| 5P1230 | CONNECTOR | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 4621654 | 12 ADAPTER | 1 | |
| 4965093 | 13 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 5041548 | 14 ADAPTER AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5060057 | 15 AIR CLEANER GP | 2 | |
| 5181671 | 16 HOSE AS | 1 | |
| 2313264 | 17 CLAMP (BOLT SPRING) | 1 | |
| 3634253 | 18 GROMMET | 1 | |
| 8T1117 | 19 CLAMP-HOSE | 3 | |
| 1226906 | 20 HOSE-HYDRAULIC (23.6-IN) |
