System And Components
344-8277 LINES GP-AIRS/N RDY1-UP
Group No: 344-8277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N5085 | 1 CLAMP | 2 | |
| 3287546 | 2 HOSE | 1 | |
| 3407241 | 3 TUBE-AIR | 1 | |
| 3430626 | 4 SUPPORT | 1 | |
| 3430627 | 5 CLAMP | 1 | |
| 3448278 | 6 TUBE AS-AIR | 1 | |
| 3655489 | 7 FLANGE | 1 | |
| 3537175 | 8 TUBE-VENTURI | 1 | |
| 1135304 | 9 SEAL-O-RING | 2 | |
| 1271570 | 10 STUD (5/16-18-THD) | 1 | |
| 1D4539 | 11 BOLT (5/16-18X2.5-IN) | 2 | |
| 2722583 | 12 SEAL-O-RING | 1 | |
| 2B2694 | 13 BOLT (5/16-18X2-IN) | 1 | |
| 3147599 | 14 CLAMP-BAND | 2 | |
| 3E4352 | 15 WASHER-HARD (8.8X20.5X2.5-MM THK) | 2 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 3696688 | 18 RETAINER | 1 |
