System And Components
496-4988 LINES GP-AIRS/N EE21-UP
Group No: 496-4988
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5078764 | 1 TUBE | 1 | |
| 3412130 | 2 HOSE | 2 | |
| 3531623 | 3 ELBOW GP-AIR INLET | 1 | |
| 4229536 | 4 HOSE-REDUCER | 1 | |
| 5078765 | 5 HOSE | 1 | |
| 5078766 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5078767 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 5107330 | 8 TUBE AS | 1 | |
| 2094590 | 9 CLAMP-T BOLT | 2 | |
| 2260087 | 10 CLAMP-T BOLT | 14 | |
| 7W2033 | 11 CLIP (TAB) | 2 | |
| 7W2034 | 12 CLIP (SLOT) | 2 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 2 |
