System And Components
523-3236 HOUSING GP-FLYWHEELS/N ENG1-UP; TXG1-UP
Group No: 523-3236
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3H0761 | 1 COVER-OPENING | 1 | |
| 9Y6089 | 2 GASKET | 1 | |
| 1084758 | 3 HOUSING AS | 1 | |
| 1W3136 | BAFFLE | 1 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 1 | |
| 0S1619 | 5 BOLT (3/8-16X3-IN) | 1 | |
| 2348937 | 6 SEAL-INTEGRAL | 1 | |
| 2721777 | 7 WASHER-HARD (11X18.5X15-MM THK) | 10 | |
| 2A1162 | 8 GASKET | 1 | |
| 2A1912 | 9 PLUG | 1 | |
| 2P2772 | 10 COVER | 1 | |
| 3B1925 | 11 WASHER (0.766X1X0.064-IN THK) | 1 | |
| 4184204 | 12 BOLT (3/8-16X2-IN) | 10 | |
| 4353128 | 13 BOLT (3/8-16X2.25-IN) | 5 | |
| 4353131 | 14 BOLT-12 POINT HEAD | 9 | |
| 4B4043 | 15 BOLT (5/8-11X1.375-IN) | 3 | |
| 5F0304 | 16 PLUG-DRAIN (5/8-18-THD) | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 5P8247 | 19 WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 7X7731 | 20 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8T6765 | 21 PLUG-PIPE (1/4-18-THD) | 2 | |
| 3190785 | 22 SEAL GP-CRANKSHAFT (REAR) | 1 | |
| 8C8422 | SEALANT |
