System And Components
578-9579 ENCLOSURE GP-ELECTRICALS/N RH8200-UP
Group No: 578-9579
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4559580 | 1 CONTROL GP-UNPROGRAMMED (ELECTRONIC) | 2 | |
| 5C9553 | 2 BOLT (M6X1X16-MM) | 6 | |
| 8T4189 | 3 BOLT (M8X1.25X20-MM) | 9 | |
| 0966166 | 4 WASHER-HARD (4.5X9X1-MM THK) | 10 | |
| 1549294 | 5 SEAL (FASTENER) | 4 | |
| 1787539 | 6 RECEPTACLE AS (POWER SUPPLY) | 1 | |
| 2225151 | 7 PAWL | 1 | |
| 2487959 | 8 STUD-TERMINAL | 1 | |
| 2869963 | 9 LATCH AS | 1 | |
| 3407161 | 10 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 3445674 | 11 NUT (M8X1.25-THD) | 8 | |
| 3T0851 | 12 LOCKNUT (M5X0.8-THD) | 12 | |
| 4812030 | 13 DOOR AS | 1 | |
| 1533723 | HINGE AS | 2 | |
| 8T5447 | RING-RETAINING | 1 | |
| 4816696 | 14 CONTROL GP-ELECTRONIC | 1 | |
| 4879669 | 15 SEAL | 1 | |
| 4H2558 | 16 GROMMET | 1 | |
| 5191366 | 17 PANEL AS-REAR | 1 | |
| 5285497 | 18 COVER AS | 1 | |
| 5414398 | 19 CABLE AS | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 9X0195 | TERMINAL-RING (0-GA, 3/8-IN SCREW) | 1 | |
| 0301708 | TERMINAL-RING (0-GA) | 1 | |
| 1355009 | TUBE-HEAT SHRINK (32-MM DIA)(16-CM) | ||
| 2761786 | COVER-TERMINAL (RED) | 1 | |
| 5428599 | 20 BOX GP-JUNCTION | 1 | |
| 4811934 | BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 4848393 | BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4885570 | PLATE AS | 1 | |
| 4885571 | PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 5138316 | PANEL AS-TOP | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 7T1099 | LINK | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 9 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 5 | |
| 5191368 | PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 5 | |
| 5191369 | PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5285499 | PANEL AS-FRONT | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 5429123 | PANEL AS-BOTTOM | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 6 | |
| 5063240 | BOSS AS | 2 | |
| 8Y3925 | BOSS (M10X1.5X30-MM) | 1 | |
| 5758495 | 21 HARNESS AS-BOX | 1 | |
| 5C2874 | 22 NUT (M5X0.8-THD) | 6 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 9 | |
| 6I1418 | 24 SPACER (8.2X12.7X28.7-MM THK) | 8 | |
| 6R7943 | 25 SCREW (M5X0.8X15-MM) | 4 | |
| 6V9491 | 26 SCREW-MACHINE (M4X0.7X20-MM) | 2 | |
| 6V9674 | 27 SCREW-MACHINE (M5X0.8X14-MM) | 2 | |
| 7K1181 | 28 STRAP-CABLE | 14 | |
| 7P1695 | 29 WASHER (10.5X19X3-MM THK) | 1 | |
| 7X0579 | 30 WASHER-HARD (8.8X25.5X2-MM THK) | 8 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 1 | |
| 8T5447 | 33 RING-RETAINING | 2 | |
| 1622165 | 34 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 8 | |
| 8T9655 | 35 MOUNT-ISOLATION | 16 | |
| 9S8752 | 36 NUT-FULL (3/8-16-THD) | 1 | |
| 9X8256 | 37 WASHER (6.6X12X2-MM THK) | 6 | |
| 5P5923 | 38 SEAL (1-M EACH) | ||
| 5P5923 | 38A SEAL (0.6-M EACH) | ||
| 1268472 | 39 SEAL (172.1-CM) |
