System And Components
381-7323 LIGHTING GP-ROADINGS/N RH81-UP
Group No: 381-7323
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4136 | 1 BOLT (M10X1.5X25-MM) | 1 | |
| 9X2040 | 2 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 4 | |
| 1305300 | 3 CLIP | 2 | |
| 8T4189 | 4 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4908 | 5 BOLT (M8X1.25X25-MM) | 4 | |
| 5C2874 | 6 NUT (M5X0.8-THD) | 2 | |
| 6V9672 | 7 SCREW-MACHINE (M4X0.7X16-MM) | 3 | |
| 8T0328 | 8 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4205 | 10 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 0962916 | 12 GROMMET | 2 | |
| 0966166 | 13 WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 2382797 | 14 LAMP GP-HEAD & SIGNAL (24-VOLT, RH) | 1 | |
| 2382798 | 15 LAMP GP-HEAD & SIGNAL (24-VOLT, LH) | 1 | |
| 2590134 | 16 LAMP GP-REGISTRATION PLATE (24-VOLT)(LICENSE) | 1 | |
| 3445673 | 17 NUT (M6X1-THD) | 6 | |
| 3445674 | 18 NUT (M8X1.25-THD) | 1 | |
| 3445675 | 19 NUT (M10X1.5-THD) | 1 | |
| 3924634 | 20 LAMP AS-INDICATOR (24-VOLT)(SIGNAL LIGHTING, LH) | 1 | |
| 3924634 | 20A LAMP AS-INDICATOR (24-VOLT)(SIGNAL LIGHTING, RH) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 4318735 | 21 FLASHER AS (12/24-VOLT) | 1 | |
| 4863674 | 22 MOUNT AS | 1 | |
| 3615420 | CLIP | 1 | |
| 4875835 | 23 PLATE | 1 | |
| 5080129 | 24 BRACKET (RH) | 1 | |
| 5080164 | 25 BRACKET (LH) | 1 |
