System And Components
381-7330 LIGHTING GP-SIGNALS/N RH81-UP
Group No: 381-7330
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1160118 | 1 CLIP | 4 | |
| 3217871 | 2 LAMP GP-SIGNAL (24-VOLT, LED, GREEN)(LH) | 1 | |
| 3217871 | 2A LAMP GP-SIGNAL (24-VOLT, LED, GREEN)(RH) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3348049 | 3 LAMP GP-SIGNAL (24-VOLT, STOP, TAIL)(LH) | 1 | |
| 3348049 | 3A LAMP GP-SIGNAL (24-VOLT, STOP, TAIL)(RH) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 4982667 | 4 BRACKET | 1 | |
| 4982668 | 5 BRACKET | 1 | |
| 5C2890 | 6 NUT (M6X1-THD) | 12 | |
| 5P4115 | 7 WASHER-HARD (7.2X19X2-MM THK) | 16 | |
| 8T4171 | 8 BOLT (M6X1X12-MM) | 4 |
