488-1130 COVER GP-ACCESS -FRONTS/N RH81-UP
Group No: 488-1130
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4136 | 1 BOLT (M10X1.5X25-MM) | 16 | |
| 7X7729 | 2 WASHER (11X25X3-MM THK) | 22 | |
| 8T4137 | 3 BOLT (M10X1.5X20-MM) | 3 | |
| 5804049 | 4 BRACKET AS | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 5205617 | 5 COVER | 3 | |
| 5232368 | 6 COVER AS (LH) | 1 | |
| 5232369 | 7 COVER AS (RH) | 1 | |
| 5233087 | 8 GUARD AS (RH) | 1 | |
| 5233090 | 9 GUARD AS (LH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5247194 | 10 BRACKET AS | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 2995675 | 11 SCREW-BUTTON HEAD (M10X1.5X30-MM) | 3 |
