Assembly
100%

381-6587 CYLINDER & MTG GP-HYDRAULIC -CONVEYORS/N RH81-UP

Group No: 381-6587
Part NumberPart NameQty
7X08181 BOLT (M8X1.25X45-MM)2
8T69122 BOLT (M8X1.25X50-MM)8
3T08523 LOCKNUT (M8X1.25-THD)2
8T42244 WASHER-HARD (8.8X16X2-MM THK)8
11543605 RING-RETAINING4
14883366 CONNECTOR AS1
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8636CONNECTOR1
14883787 ELBOW AS3
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8724ELBOW1
14884358 TEE AS2
3J1907SEAL-O-RING1
6V8397SEAL-O-RING2
6V8781TEE1
27025759 PIN2
420648210 CYLINDER GP-HYDRAULIC (SWING)1
499883611 VALVE GP-FLOW CONTROL (HYDRAULIC)2
4650407SEAL-O-RING2
514758912 CYLINDER GP-LIFT (LH)1
514758912A CYLINDER GP-LIFT (RH)1
541760913 PIN-LINKAGE2
541943014 PIN-LINKAGE2
3B463115 PIN-COTTER2
7X059716 WASHER-HARD (31X56X4-MM THK)10
