Assembly
100%

381-6591 CYLINDER & MTG GP-HYDRAULIC -STEERINGS/N RH81-UP

Group No: 381-6591
Part NumberPart NameQty
8T41911 BOLT (M10X1.5X16-MM)2
8T69122 BOLT (M8X1.25X50-MM)8
3T08523 LOCKNUT (M8X1.25-THD)1
7X05374 WASHER-HARD (40.5X67X6-MM THK)2
8T41215 WASHER-HARD (11X21X2.5-MM THK)2
8T42246 WASHER-HARD (8.8X16X2-MM THK)8
8T42407 RING-RETAINING4
8T68698 BOLT (M8X1.25X60-MM)1
9R01589 WASHER (46X69X3-MM THK)3
148833610 CONNECTOR AS2
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8636CONNECTOR1
148835311 ELBOW AS1
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V9001ELBOW1
148836712 ELBOW AS1
6V8397SEAL-O-RING1
6V9850ELBOW1
148837813 ELBOW AS1
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8724ELBOW1
397362114 PIN1
482405415 PIN2
482405516 PIN1
499883717 VALVE GP-FLOW CONTROL2
4650407SEAL-O-RING2
520544118 CYLINDER GP-HYDRAULIC1
523022719 GUARD1
540935820 CYLINDER GP-STEERING1
6V321321 RING-RETAINING3
