Assembly
100%

381-6666 ANTISLAB & MOUNTING GPS/N RH8200-UP

Group No: 381-6666
Part NumberPart NameQty
38246121 PLATE AS5
8T42262 WASHER-PLATED (10.5X45X3-MM THK)7
8T46483 BOLT (M12X1.75X70-MM)15
46802604 PIN AS2
8T42235 WASHER-HARD (13.5X25.5X3-MM THK)30
46802676 BELT1
09100817 SPACER (10.5X20X10-MM THK)2
32933568 NUT (M12X1.75-THD)15
49374059 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)3
542169610 BELT1
542642911 PLATE1
586687312 ANTISLAB AS1
8T3490NUT-WELD (M10X1.5-THD)2
3864410PLATE3
7X772913 WASHER (11X25X3-MM THK)5
8T412114 WASHER-HARD (11X21X2.5-MM THK)4
8T413615 BOLT (M10X1.5X25-MM)4
8T413716 BOLT (M10X1.5X20-MM)5
468040417 GUARD1
8T419518 BOLT (M10X1.5X30-MM)7
8T422219 WASHER-PLATED (11X32X2.5-MM THK)2
