System And Components
560-6162 CONTROL & MTG GP-ELHYDS/N RH8200-UP
Group No: 560-6162
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9553 | 1 BOLT (M6X1X16-MM) | 11 | |
| 7X2536 | 2 BOLT (M8X1.25X14-MM) | 4 | |
| 8T4200 | 3 BOLT (M8X1.25X16-MM) | 2 | |
| 3T6522 | 4 PIN | 1 | |
| 5P4115 | 5 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 5P4116 | 6 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 6R7943 | 7 SCREW (M5X0.8X15-MM) | 4 | |
| 6V8757 | 8 RING-RETAINING | 1 | |
| 7C4354 | 9 CLIP | 2 | |
| 7K1181 | 10 STRAP-CABLE | 6 | |
| 7X0605 | 11 WASHER-HARD (13X28X1.6-MM THK) | 2 | |
| 8T4138 | 12 BOLT (M6X1X20-MM) | 1 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2044 | 14 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 9X2132 | 15 RETAINER | 1 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 10 | |
| 1146658 | 17 WASHER (6.5X17X1-MM THK) | 2 | |
| 1608500 | 18 NUT (M8X1.25-THD) | 1 | |
| 2333246 | 19 SPRING | 1 | |
| 2333247 | 20 BUSHING | 2 | |
| 2333248 | 21 BUSHING | 2 | |
| 2333252 | 22 SHAFT AS | 1 | |
| 2692893 | 23 CLIP | 1 | |
| 2939452 | 24 MOUNTING-CABLE TIE | 1 | |
| 4746163 | 25 WASHER (12.5X65X4-MM THK) | 1 | |
| 2114942 | 26 KNOB AS | 1 | |
| 8T0277 | PIN-SPRING | 1 | |
| 3445673 | 27 NUT (M6X1-THD) | 3 | |
| 4836363 | 28 LEVER | 1 | |
| 5909174 | 29 LEVER AS | 1 | |
| 5557673 | 30 HEAD | 1 | |
| 5557694 | 31 HANDLE | 1 | |
| 5606175 | 32 SUPPORT AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 5606177 | 33 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8R3857 | BOSS (M8X1.25X12-MM) | 2 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 4 | |
| 3615420 | CLIP | 2 | |
| 5606186 | 34 LATCH AS | 1 | |
| 5606207 | 35 STRUT AS | 1 | |
| 5606208 | 36 CABLE AS | 1 | |
| 5631316 | 37 BEARING-SLEEVE | 2 | |
| 5631317 | 38 WASHER-THRUST (55.25X80X3-MM THK) | 1 | |
| 5631361 | 39 PLATE | 1 | |
| 5631373 | 40 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 5667167 | 41 MODULE GP-KEYPAD | 1 | |
| 8F1326 | WASHER (4.2X9.5X0.8-MM THK) | 2 | |
| 8T2659 | LOCKNUT (M4X0.7-THD) | 2 | |
| 5678269 | 42 COVER AS (RH) | 1 | |
| 5678283 | 43 COVER AS (LH) | 1 | |
| 5678390 | 44 CUSHION AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 5 | |
| 5772989 | 45 BEARING-SLEEVE | 1 | |
| 5793318 | 46 HARNESS AS-CONTROL (ARMREST, RH) | 1 | |
| 5829450 | 47 SCREW-FLAT HEAD (M5X0.8X25-MM) | 4 | |
| 5914466 | 48 SUPPORT AS | 1 | |
| 5914468 | 49 TUBE | 1 | |
| 5914469 | 50 SUPPORT AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 1696378 | BOSS (M10X1.5X33-MM) | 1 | |
| 5914471 | 51 PLATE | 1 | |
| 1U4014 | 52 PIN | 1 | |
| 3G0622 | 53 RING-RETAINING | 2 | |
| 6V9676 | 54 SETSCREW-SOCKET (M6X1X16-MM) | 3 | |
| 8T4908 | 55 BOLT (M8X1.25X25-MM) | 4 | |
| 9X2038 | 56 WASHER (7X19X2-MM THK) | 2 | |
| 9X2043 | 57 SCREW-TRUSS HEAD (M6X1X14-MM) | 6 | |
| 9X2045 | 58 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 |
