System And Components
577-6229 LINES GP-PROPELS/N NJX200-UP
Group No: 577-6229
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4182 | 1 BOLT (M10X1.5X45-MM) | 12 | |
| 7X0818 | 2 BOLT (M8X1.25X45-MM) | 2 | |
| 7X2533 | 3 BOLT (M6X1X35-MM) | 2 | |
| 8T4200 | 4 BOLT (M8X1.25X16-MM) | 1 | |
| 1028705 | 5 PLATE (TOP) | 1 | |
| 1074749 | 6 PLATE (TOP) | 1 | |
| 1241479 | 7 CLIP (LOOP) | 2 | |
| 1439644 | 8 PLATE-RETAINER | 1 | |
| 1488367 | 9 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488375 | 10 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8981 | ELBOW | 1 | |
| 1488457 | 11 UNION AS (STRAIGHT) | 3 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 1495452 | 12 UNION AS (STRAIGHT) | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 1504052 | 13 UNION AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8993 | UNION | 1 | |
| 1536241 | 14 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8C8989 | ELBOW | 1 | |
| 1536246 | 15 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 7X0820 | TEE | 1 | |
| 1772215 | 16 STRAP-DUAL CLAMP | 12 | |
| 1783620 | 17 STRAP-DUAL CLAMP | 3 | |
| 1P3702 | 18 SEAL-RECTANGULAR | 3 | |
| 1P3704 | 19 SEAL-RECTANGULAR | 1 | |
| 1P5767 | 20 FLANGE-HALF | 2 | |
| 2061511 | 21 CLAMP-HALF | 2 | |
| 2066411 | 22 CLAMP-HALF | 4 | |
| 2066415 | 23 CLAMP-HALF | 2 | |
| 2322496 | 24 CLAMP-HALF | 2 | |
| 2905562 | 25 MOUNT (DUAL SWIVEL) | 2 | |
| 2P1279 | 26 LOCKNUT (9/16-18-THD) | 1 | |
| 3025329 | 27 STUD (M10X1.5X105-MM) | 12 | |
| 3445675 | 28 NUT (M10X1.5-THD) | 26 | |
| 3644568 | 29 STRAP | 7 | |
| 4365944 | 30 PLATE | 1 | |
| 4827298 | 31 HOSE AS | 1 | |
| 4827300 | 32 HOSE AS | 1 | |
| 4827308 | 33 HOSE AS | 1 | |
| 4827317 | 34 HOSE AS | 1 | |
| 4827318 | 35 HOSE AS | 1 | |
| 4827320 | 36 HOSE AS | 1 | |
| 4827321 | 37 HOSE AS | 1 | |
| 4827322 | 38 HOSE AS | 1 | |
| 4852633 | 39 HOSE AS | 1 | |
| 4852634 | 40 HOSE AS | 1 | |
| 4852635 | 41 HOSE AS | 1 | |
| 4852636 | 42 HOSE AS | 1 | |
| 4852649 | 43 HOSE AS | 1 | |
| 4852650 | 44 HOSE AS | 1 | |
| 4852651 | 45 HOSE AS | 1 | |
| 4852654 | 46 SPACER (11.2X16X55-MM THK) | 12 | |
| 4852655 | 47 BLOCK | 6 | |
| 4852656 | 48 BLOCK | 6 | |
| 4852657 | 49 BLOCK | 6 | |
| 4852658 | 50 PLATE AS | 6 | |
| 4170628 | LINK | 2 | |
| 4852664 | 51 HOSE AS | 1 | |
| 4852703 | 52 CLAMP | 2 | |
| 4883746 | 53 PLATE | 1 | |
| 4910371 | 54 PLATE | 3 | |
| 4910372 | 55 HOSE AS | 1 | |
| 4910373 | 56 HOSE AS | 1 | |
| 5230272 | 57 HOSE AS | 1 | |
| 5230273 | 58 HOSE AS | 1 | |
| 5230274 | 59 HOSE AS | 1 | |
| 5230275 | 60 HOSE AS | 1 | |
| 5394505 | 61 HOSE AS | 1 | |
| 5394506 | 62 HOSE AS | 1 | |
| 5394507 | 63 HOSE AS | 1 | |
| 5619966 | 64 HOSE AS | 1 | |
| 5619967 | 65 HOSE AS | 1 | |
| 6V9168 | 66 NUT (11/16-16-THD) | 3 | |
| 6V9169 | 67 NUT (13/16-16-THD) | 5 | |
| 7K1181 | 68 STRAP-CABLE | 12 | |
| 7R7939 | 69 CLAMP-PIPE | 6 | |
| 7X2535 | 70 BOLT (M6X1X60-MM) | 6 | |
| 8T4121 | 71 WASHER-HARD (11X21X2.5-MM THK) | 28 | |
| 8T4194 | 72 BOLT (M12X1.75X50-MM) | 4 | |
| 8T4223 | 73 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 74 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T6466 | 75 BOLT (M10X1.5X60-MM) | 2 | |
| 8T6869 | 76 BOLT (M8X1.25X60-MM) | 1 | |
| 8T9403 | 77 FLANGE-HALF | 6 | |
| 9X2480 | 78 BOLT (M6X1X45-MM) | 2 |
