System And Components
570-4425 LINES GP-LIFT CYLINDERS/N NJX200-UP
Group No: 570-4425
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042281 | 1 STRAP-CABLE | 3 | |
| 7X0818 | 2 BOLT (M8X1.25X45-MM) | 4 | |
| 7X2537 | 3 BOLT (M8X1.25X35-MM) | 7 | |
| 6V8397 | 4 SEAL-O-RING | 1 | |
| 0993649 | 5 BOLT (M8X1.25X40-MM) | 2 | |
| 1028703 | 6 PLATE-COVER | 8 | |
| 1028705 | 7 PLATE (TOP) | 4 | |
| 1544880 | 8 CLAMP-HALF | 2 | |
| 8V5718 | 9 CLAMP | 8 | |
| 1772215 | 10 STRAP-DUAL CLAMP | 1 | |
| 2066409 | 11 CLAMP-HALF | 6 | |
| 2905562 | 12 MOUNT (DUAL SWIVEL) | 1 | |
| 4883746 | 13 PLATE | 1 | |
| 5220308 | 14 TUBE AS | 1 | |
| 5220310 | 15 TUBE AS | 1 | |
| 5230283 | 16 TUBE AS | 1 | |
| 5230284 | 17 TUBE AS | 1 | |
| 1563618 | 18 CLAMP-HALF | 10 | |
| 5202988 | 19 HOSE AS | 1 | |
| 5202989 | 20 HOSE AS | 1 | |
| 5220304 | 21 HOSE AS | 1 | |
| 5220305 | 22 HOSE AS | 1 | |
| 5776210 | 23 HOSE AS | 1 | |
| 5776219 | 24 HOSE AS | 1 | |
| 6D4247 | 25 CLIP | 1 | |
| 7K1181 | 26 STRAP-CABLE | 2 |
