System And Components
416-4726 VALVE GP-AIR CONTROLS/N NJX1-UP
Group No: 416-4726
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3438109 | 1 ELBOW-OUTLET | 1 | |
| 3653006 | 2 VALVE GP-AIR CONTROL | 1 | |
| 3893708 | 3 PLUG AS | 2 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 4152405 | 4 MANIFOLD GP-INLET | 1 | |
| 4152415 | 5 HOSE-AIR | 1 | |
| 4173556 | 6 TUBE AS | 1 | |
| 4173558 | 7 BRACKET AS | 1 | |
| 4173560 | 8 ELBOW-AIR INLET | 1 | |
| 4173561 | 9 BRACKET | 1 | |
| 1246275 | 10 CLAMP-HOSE | 2 | |
| 1837121 | 11 BOLT (M10X1.5X35-MM) | 2 | |
| 2147568 | 12 SEAL-O-RING | 1 | |
| 8T6869 | 13 BOLT (M8X1.25X60-MM) | 4 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 7X2538 | 15 BOLT (M8X1.25X100-MM) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 3 | |
| 5C9553 | 18 BOLT (M6X1X16-MM) | 1 | |
| 3535103 | 19 ADAPTER AS | 1 | |
| 0307942 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5P4924 | 20 ELBOW | 1 | |
| 6V7357 | 21 BOLT (M6X1X25-MM) | 2 |
