Assembly
100%

560-6192 SEAT & MOUNTING GPS/N NJX200-UP

Group No: 560-6192
Part NumberPart NameQty
7X25411 BOLT (M8X1.25X140-MM)1
8T41892 BOLT (M8X1.25X20-MM)4
8T49703 BOLT (M6X1X14-MM)4
3T08524 LOCKNUT (M8X1.25-THD)1
5C28745 NUT (M5X0.8-THD)4
6R79436 SCREW (M5X0.8X15-MM)16
6V73577 BOLT (M6X1X25-MM)2
7X77298 WASHER (11X25X3-MM THK)12
8T03289 WASHER-HARD (5.5X10X1-MM THK)16
8T413610 BOLT (M10X1.5X25-MM)12
8T422411 WASHER-HARD (8.8X16X2-MM THK)6
9X825612 WASHER (6.6X12X2-MM THK)6
127217013 SCREW-TRUSS HEAD (M8X1.25X20-MM)2
222515114 PAWL1
286996315 LATCH AS1
298778816 BUMPER2
483185817 RAIL AS2
483191518 BASE AS-SEAT1
8T3612NUT-WELD (M8X1.25-THD)4
483316719 PLATE1
539894020 PIN AS1
541943521 SEAT GP-SUSPENSION1
560620922 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
560621023 DOOR AS-ACCESS1
1533723HINGE AS2
8T5447RING-RETAINING1
560621624 COVER AS1
567933325 PANEL1
577297726 PLATE1
577297827 KEY1
577299028 BEARING-SLEEVE1
577299929 COVER1
578583430 FLOOR MAT1
578583531 FOAM3
591443232 BASE AS-SEAT1
7T1099LINK3
8T3490NUT-WELD (M10X1.5-THD)5
8T3612NUT-WELD (M8X1.25-THD)2
8T032533 BOLT (M5X0.8X14-MM)12
126847234 SEAL (28-CM)
9X638235 SEAL (51-CM)
