System And Components
Assembly
100%

381-6632 BELT TENSIONER GPS/N J631-UP

Group No: 381-6632
Part NumberPart NameQty
8T41951 BOLT (M10X1.5X30-MM)12
7X25332 BOLT (M6X1X35-MM)2
8T41403 BOLT (M16X2X60-MM)6
8T73384 BOLT (M16X2X45-MM)2
1B87445 KEY-WOODRUFF2
1G87816 CLAMP (HALF)2
3E94117 WASHER-HARD (17.5X38X6-MM THK)2
6V87548 RING-RETAINING4
7X05159 WASHER-HARD (17X35X5-MM THK)2
8T412110 WASHER-HARD (11X21X2.5-MM THK)12
8T413211 NUT (M16X2-THD)2
107474912 PLATE (TOP)(TOP)1
171297213 GAUGE-SIGHT1
194290314 ELBOW AS1
3K0360SEAL-O-RING1
8T0119ELBOW1
197915515 BREATHER (BELT TENSIONER)1
267882116 WASHER (17X36X12-MM THK)6
352649017 PLUG AS1
6V9507PLUG1
2287088SEAL-O-RING1
398559618 PLUG AS1
2385080SEAL-O-RING1
3603680PLUG (3/4-16-THD)1
434328819 SEAL-V-RING2
564841120 CAP2
485547021 BEARING-SLEEVE4
507540922 SHAFT-STUB2
507561423 BELT TENSIONER GP2
195852423A BEARING (100-MM OD, 55-MM ID)2
0965516RING-RETAINING (EXTERNAL)1
4821262IDLER AS1
5077311IDLER AS1
509251624 PIN2
511536625 SHAFT GP-DRIVE1
532508826 KEY2
533295827 HOSE AS1
540006628 HOUSING AS1
8T3597NUT-WELD (M12X1.75-THD)4
1028704PLATE-WELD1
541509629 HOUSING-BEARING1
154523230 ADAPTER AS1
3K0360SEAL-O-RING1
4J5477SEAL-O-RING1
1129783ADAPTER1
170855631 BOLT (M16X2X140-MM)2
355734032 SEAL-LIP TYPE2
3F575033 RACE-ROLLER BEARING1
5P828634 SEAL-O-RING1
8L278635 SEAL-O-RING1
144733936 SEAL-O-RING2
6V622837 SEAL-O-RING2
