System And Components
518-2970 ENCLOSURE GP-REARS/N JHZ1-UP
Group No: 518-2970
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4183 | 1 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4195 | 2 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 3 BOLT (M10X1.5X35-MM) | 6 | |
| 7X2553 | 4 BOLT (M16X2X40-MM) | 2 | |
| 8T4189 | 5 BOLT (M8X1.25X20-MM) | 31 | |
| 8T4200 | 6 BOLT (M8X1.25X16-MM) | 4 | |
| 1111777 | 7 BUMPER-RUBBER | 2 | |
| 2225151 | 8 PAWL | 1 | |
| 2567669 | 9 PLATE | 2 | |
| 2813974 | 10 BUMPER | 1 | |
| 2869963 | 11 LATCH AS | 1 | |
| 2M5795 | 12 PIN-CLEVIS | 1 | |
| 3053169 | 13 PAWL | 1 | |
| 3260610 | 14 LATCH AS | 1 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0966331 | NUT (M12X1.75-THD) | 2 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 3260612 | WASHER-TAB | 2 | |
| 3445675 | 15 NUT (M10X1.5-THD) | 2 | |
| 3B4607 | 16 PIN-COTTER | 1 | |
| 4678842 | 17 RETAINER (LATCH) | 1 | |
| 4772864 | 18 COVER | 1 | |
| 4898228 | 19 HINGE AS | 2 | |
| 5182979 | 20 DOOR AS-REAR | 1 | |
| 1S2199 | DOWEL | 1 | |
| 5202920 | 21 INSULATION | 1 | |
| 5215116 | 22 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5400081 | 23 PANEL AS-DOOR | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 9J5709 | PLUG-BUTTON | 1 | |
| 2945046 | NUT-WELD | 3 | |
| 5403909 | 24 GUARD AS | 1 | |
| 5416940 | 25 PANEL AS-DOOR | 1 | |
| 5416950 | 26 COVER | 1 | |
| 5420218 | 27 DOOR (BUMPER) | 1 | |
| 5421710 | 28 BRACKET | 1 | |
| 5475527 | 29 PLATE | 1 | |
| 5486917 | 30 PANEL AS-DOOR | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5624301 | 31 PANEL AS-ENCLOSURE | 1 | |
| 5400073 | PLATE AS | 1 | |
| 7T1099 | LINK | 2 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 2 | |
| 5416933 | PANEL AS-DOOR | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 7 | |
| 5621955 | BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5624304 | 32 PANEL AS-ENCLOSURE | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 7T1099 | LINK | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 8 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 5630528 | 33 PANEL AS-SIDE | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3615420 | CLIP | 2 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P4116 | 35 WASHER-HARD (8.8X20.5X2-MM THK) | 27 | |
| 5Y0660 | 36 NUT (M6X1-THD) | 1 | |
| 6P6256 | 37 RETAINER-SPRING | 6 | |
| 7X7729 | 38 WASHER (11X25X3-MM THK) | 40 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 28 | |
| 8T4224 | 41 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9M3835 | 42 LATCH-RUBBER | 1 | |
| 9X8257 | 43 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 5P5944 | 44 TRIM (1-M) | ||
| 5P6410 | 45 SEAL (1.9-M) | ||
| 5P6410 | 45A SEAL (0.4-M) | ||
| 1495933 | 46 SEAL (39.5-CM) |
