System And Components
378-1920 LINES GP-AIRS/N E5K1-UP
Group No: 378-1920
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 1 | |
| 2177088 | 2 HOSE | 1 | |
| 2178946 | 3 ELBOW | 1 | |
| 3412130 | 4 HOSE | 1 | |
| 3869921 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 4222655 | 6 TUBE AS | 1 | |
| 4222656 | 7 TUBE | 1 | |
| 4229536 | 8 HOSE-REDUCER | 2 | |
| 4387209 | 9 TUBE | 1 | |
| 4387230 | 10 HOSE | 1 | |
| 4387233 | 11 TUBE | 1 | |
| 4387263 | 12 HOSE-AIR | 1 | |
| 4387265 | 13 HOSE-AIR | 1 | |
| 4447118 | 14 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 1997854 | 15 SPACER (11.8X20X45-MM THK) | 1 | |
| 2162211 | 16 CLAMP | 8 | |
| 2260087 | 17 CLAMP-T BOLT | 8 | |
| 2860693 | 18 SPACER (11X25X18-MM THK) | 1 | |
| 3072671 | 19 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 5P1076 | 20 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V6782 | 21 CLIP (SLOT) | 1 | |
| 6V6783 | 22 CLIP (TAB) | 1 | |
| 7L6326 | 23 CLIP | 1 | |
| 7W2033 | 24 CLIP (TAB) | 2 | |
| 7W2034 | 25 CLIP (SLOT) | 2 | |
| 7X7729 | 26 WASHER (11X25X3-MM THK) | 6 | |
| 8C3089 | 27 SEAL-O-RING | 1 | |
| 8T4178 | 28 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4183 | 29 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4195 | 30 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4956 | 31 BOLT (M12X1.75X35-MM) | 1 | |
| 8T4987 | 32 CLAMP-HOSE | 2 | |
| 8T6703 | 33 CLAMP-HOSE | 4 |
