System And Components
381-1956 LINES GP-PROPELS/N E5K1-UP
Group No: 381-1956
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1544892 | 1 BOLT-STACKING (M8X1.25X61-MM) | 2 | |
| 2072386 | 2 BOLT-STACKING (M6X1.25X49-MM) | 2 | |
| 7K1181 | 3 STRAP-CABLE | 20 | |
| 1158645 | 4 GUARD | 2 | |
| 1439644 | 5 PLATE-RETAINER | 3 | |
| 2060452 | 6 PLATE | 2 | |
| 2072387 | 7 PLATE | 1 | |
| 2074499 | 8 PLATE-COVER | 7 | |
| 2887158 | 9 STUD (M10X1.5X125-MM) | 8 | |
| 2964400 | 10 STRAP AS | 2 | |
| 3583156 | 11 STUD (M12X1.75X85-MM) | 4 | |
| 3644569 | 12 STRAP | 2 | |
| 3644570 | 13 STRAP | 5 | |
| 4161374 | 14 HOSE AS | 4 | |
| 4161382 | 15 HOSE AS | 1 | |
| 4655666 | 16 HOSE AS | 1 | |
| 4161386 | 17 HOSE AS | 2 | |
| 4365809 | 18 HOSE AS | 2 | |
| 4365811 | 19 HOSE AS | 1 | |
| 4365812 | 20 HOSE AS | 1 | |
| 4655667 | 21 HOSE AS | 1 | |
| 4365814 | 22 HOSE AS | 1 | |
| 4365815 | 23 HOSE AS | 1 | |
| 4365816 | 24 HOSE AS | 1 | |
| 4365817 | 25 HOSE AS | 1 | |
| 4365818 | 26 HOSE AS | 1 | |
| 4365944 | 27 PLATE | 17 | |
| 4422509 | 28 SPACER (11.2X16X75.6-MM THK) | 8 | |
| 4435955 | 29 HOSE AS | 2 | |
| 4547623 | 30 HOSE AS | 2 | |
| 4547625 | 31 PLATE | 1 | |
| 4547627 | 32 PLATE | 4 | |
| 4547628 | 33 BLOCK | 4 | |
| 4547629 | 34 BLOCK | 4 | |
| 4547630 | 35 BLOCK | 4 | |
| 4547632 | 36 HOSE AS | 4 | |
| 4547711 | 37 HOSE AS | 1 | |
| 4547712 | 38 HOSE AS | 1 | |
| 4549530 | 39 HOSE AS | 1 | |
| 1325789 | 40 CLIP (LADDER) | 1 | |
| 1488352 | 41 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488376 | 42 ELBOW AS | 4 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1488455 | 43 UNION AS | 4 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1646862 | 44 TEE AS | 1 | |
| 6V9160 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 3 | |
| 1783620 | 45 STRAP-DUAL CLAMP | 4 | |
| 1P3702 | 46 SEAL-RECTANGULAR | 4 | |
| 1P3703 | 47 SEAL-RECTANGULAR | 4 | |
| 1P4579 | 48 FLANGE-HALF | 2 | |
| 2006345 | 49 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 50 STRAP-CABLE | 2 | |
| 2061511 | 51 CLAMP-HALF | 4 | |
| 1544884 | 52 CLAMP-HALF | 48 | |
| 2080075 | 53 CLAMP-HALF | 4 | |
| 2416197 | 54 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 2416196 | TEE | 1 | |
| 2501488 | 55 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 1547159 | TEE | 1 | |
| 2P1293 | 56 LOCKNUT (1-3/16-12-THD) | 9 | |
| 3293356 | 57 NUT (M12X1.75-THD) | 4 | |
| 3445675 | 58 NUT (M10X1.5-THD) | 16 | |
| 4J0524 | 59 SEAL-O-RING | 1 | |
| 5P4116 | 60 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6V0400 | 61 FLANGE-HALF | 8 | |
| 6V9172 | 62 NUT (1-7/16-12-THD) | 2 | |
| 7G5984 | 63 CLIP (TAB) | 2 | |
| 7G5985 | 64 CLIP (SLOT) | 2 | |
| 7X7729 | 65 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 66 WASHER-HARD (11X21X2.5-MM THK) | 28 | |
| 8T4191 | 67 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4182 | 68 BOLT (M10X1.5X45-MM) | 16 | |
| 8T4183 | 69 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 70 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4195 | 71 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4223 | 72 WASHER-HARD (13.5X25.5X3-MM THK) | 24 | |
| 8T6703 | 73 CLAMP-HOSE | 1 | |
| 8T6869 | 74 BOLT (M8X1.25X60-MM) | 21 | |
| 2859066 | 75 BOLT (M8X1.25X65-MM) | 1 | |
| 8T9403 | 76 FLANGE-HALF | 8 | |
| 9X2480 | 77 BOLT (M6X1X45-MM) | 6 | |
| 1602252 | 78 SLEEVE-ABRASION (53-IN EACH) | ||
| 3644568 | 79 STRAP | 2 | |
| 6D4246 | 80 CLIP (LOOP) | 2 | |
| 8T4224 | 81 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6912 | 82 BOLT (M8X1.25X50-MM) | 2 | |
| 1544881 | 83 CLAMP-HALF | 4 |
