System And Components
379-9549 PUMP GP-WATER & ADDITIVE SPRAYS/N E5K1-UP
Group No: 379-9549
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5E8194 | 1 PLUG | 1 | |
| 9N7802 | 2 VALVE | 2 | |
| 3255845 | 3 BRACKET AS | 1 | |
| 3278575 | 4 FLANGE | 1 | |
| 3814293 | 5 SKID AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 6 | |
| 3814296 | 6 FLANGE AS | 2 | |
| 3814297 | 7 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3814298 | 8 BRACKET | 1 | |
| 3814299 | 9 PIPE AS | 1 | |
| 3814300 | 10 PIPE AS | 1 | |
| 3814301 | 11 PIPE AS | 1 | |
| 3931145 | 12 VALVE (WATER SPRAY) | 1 | |
| 4238727 | 13 PUMP GP-WATER & ADDITIVE SPRAY | 1 | |
| 4238728 | 14 STRAINER GP (WATER SPRAY) | 1 | |
| 0951720 | SEAL-O-RING | 1 | |
| 4575661 | STRAINER (WATER SPRAY) | 1 | |
| 5508514 | 15 VALVE-BALL | 1 | |
| 4238731 | 16 MOUNT | 1 | |
| 4935898 | 17 COUPLING AS-DRIVE | 1 | |
| 4935899 | HUB | 1 | |
| 4935900 | HUB | 1 | |
| 4935901 | INSERT | 1 | |
| 4935903 | SLEEVE | 1 | |
| 4975518 | 18 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4238735 | 19 COVER | 1 | |
| 5425236 | 20 LEVER AS | 1 | |
| 4238771 | 21 GUARD | 1 | |
| 2094579 | 23 CLAMP | 4 | |
| 4238732 | 24 HOSE (35-CM) | ||
| 8T4195 | 25 BOLT (M10X1.5X30-MM) | 4 | |
| 5P1076 | 26 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 7X0515 | 27 WASHER-HARD (17X35X5-MM THK) | 4 | |
| 7X2553 | 28 BOLT (M16X2X40-MM) | 4 | |
| 7X2555 | 29 BOLT (M16X2X80-MM) | 20 | |
| 8C6905 | 30 FITTING-REDUCER | 1 | |
| 8T0389 | 31 LOCKNUT (M10X1.5-THD) | 4 | |
| 8T3865 | 32 GASKET | 5 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 22 | |
| 8T4122 | 34 WASHER-HARD (17X32X3.5-MM THK) | 40 | |
| 8T4132 | 35 NUT (M16X2-THD) | 20 | |
| 8T4171 | 36 BOLT (M6X1X12-MM) | 3 | |
| 8T4183 | 37 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4186 | 38 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4196 | 39 BOLT (M10X1.5X35-MM) | 12 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4956 | 41 BOLT (M12X1.75X35-MM) | 8 | |
| 9X8256 | 42 WASHER (6.6X12X2-MM THK) | 3 | |
| 4975519 | 43 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 4975517 | 44 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 7X7729 | 45 WASHER (11X25X3-MM THK) | 6 | |
| 3445675 | 46 NUT (M10X1.5-THD) | 4 | |
| 8T4205 | 47 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 7X2535 | 48 BOLT (M6X1X60-MM) | 1 | |
| 5A3604 | 49 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 1 |
