System And Components
535-8708 LINES GP-PROPELS/N AK31-UP; Z4M1-UP
Group No: 535-8708
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042281 | 1 STRAP-CABLE | 7 | |
| 8T4182 | 2 BOLT (M10X1.5X45-MM) | 14 | |
| 7X0818 | 3 BOLT (M8X1.25X45-MM) | 15 | |
| 7X2533 | 4 BOLT (M6X1X35-MM) | 2 | |
| 7X2537 | 5 BOLT (M8X1.25X35-MM) | 3 | |
| 8T6912 | 6 BOLT (M8X1.25X50-MM) | 3 | |
| 6V8397 | 7 SEAL-O-RING | 2 | |
| 8C8451 | 8 BOLT (M6X1X40-MM) | 6 | |
| 1028703 | 9 PLATE-COVER | 3 | |
| 1028705 | 10 PLATE (TOP) | 2 | |
| 1074749 | 11 PLATE | 1 | |
| 1384572 | 12 COVER | 5 | |
| 1439644 | 13 PLATE-RETAINER | 2 | |
| 1488376 | 14 ELBOW AS | 4 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1536246 | 15 TEE AS | 3 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 7X0820 | TEE | 1 | |
| 1544881 | 16 CLAMP-HALF | 4 | |
| 1544891 | 17 BOLT-STACKING (M8X1.25X49-MM) | 6 | |
| 1563617 | 18 CLAMP-HALF | 6 | |
| 1646862 | 19 TEE AS | 2 | |
| 6V9160 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 3 | |
| 1697409 | 20 UNION AS | 4 | |
| 6V8996 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1783620 | 21 STRAP-DUAL CLAMP | 12 | |
| 1964206 | 22 BOLT-STACKING (M6X1X64-MM) | 2 | |
| 1P3702 | 23 SEAL-RECTANGULAR | 4 | |
| 2006345 | 24 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2060451 | 25 BOLT-STACKING (M8X1.25X44-MM) | 2 | |
| 2060452 | 26 PLATE | 2 | |
| 2066411 | 27 CLAMP-HALF | 4 | |
| 2080075 | 28 CLAMP-HALF | 4 | |
| 2322496 | 29 CLAMP-HALF | 2 | |
| 2374257 | 30 CLAMP-HALF | 44 | |
| 2823736 | 31 STUD (M10X1.2X45-MM) | 2 | |
| 2P1293 | 32 LOCKNUT (1-3/16-12-THD) | 6 | |
| 4367243 | 33 HOSE AS | 2 | |
| 4367247 | 34 HOSE AS | 2 | |
| 4435955 | 35 HOSE AS | 2 | |
| 4883746 | 36 PLATE | 11 | |
| 5358724 | 37 HOSE AS | 1 | |
| 5358725 | 38 HOSE AS | 2 | |
| 5358727 | 39 HOSE AS | 2 | |
| 5358728 | 40 HOSE AS | 1 | |
| 5431339 | 41 HOSE AS | 1 | |
| 5431340 | 42 HOSE AS | 1 | |
| 5587326 | 43 HOSE AS | 1 | |
| 5587327 | 44 HOSE AS | 1 | |
| 5623918 | 45 HOSE AS | 1 | |
| 5623920 | 46 HOSE AS | 2 | |
| 5623921 | 47 HOSE AS | 2 | |
| 5629434 | 48 BRACKET AS | 1 | |
| 1028704 | PLATE-WELD | 1 | |
| 1544886 | PLATE AS | 1 | |
| 1788508 | PLATE AS | 1 | |
| 4170628 | LINK | 2 | |
| 5638779 | 49 HOSE AS | 1 | |
| 5638780 | 50 HOSE AS | 1 | |
| 5638781 | 51 HOSE AS | 1 | |
| 5638782 | 52 HOSE AS | 1 | |
| 5780773 | 53 HOSE AS | 1 | |
| 5780774 | 54 HOSE AS | 1 | |
| 5780779 | 55 HOSE AS | 1 | |
| 5824132 | 56 BRACKET AS | 1 | |
| 1028706 | PLATE AS | 1 | |
| 6V9168 | 57 NUT (11/16-16-THD) | 3 | |
| 6V9170 | 58 NUT-BULKHEAD (1-14-THD) | 4 | |
| 7R7908 | 59 CLAMP | 6 | |
| 7R7939 | 60 CLAMP-PIPE | 4 | |
| 7R7951 | 61 PLATE | 1 | |
| 7R7955 | 62 PLATE (SLOTTED) | 1 | |
| 7V5628 | 63 PLATE (TOP) | 3 | |
| 7X2535 | 64 BOLT (M6X1X60-MM) | 2 | |
| 8T4121 | 65 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 66 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4896 | 67 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 8T9403 | 68 FLANGE-HALF | 8 | |
| 9X2480 | 69 BOLT (M6X1X45-MM) | 4 |
