System And Components
545-6194 LINES GP-AIRS/N R4H1-UP; R2J1-UP
Group No: 545-6194
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042281 | 1 STRAP-CABLE | 5 | |
| 1516119 | 2 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1622254 | SEAL | 1 | |
| 3960392 | ADAPTER | 1 | |
| 6L1883 | 3 GASKET | 2 | |
| 8T4189 | 4 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4648 | 5 BOLT (M12X1.75X70-MM) | 2 | |
| 5P4116 | 6 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 6V8260 | 7 SEAL-O-RING | 1 | |
| 7C4354 | 8 CLIP | 2 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 4 | |
| 7X7958 | 10 CLAMP-HOSE | 4 | |
| 8T0328 | 11 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8T1885 | 12 CLIP (SLOT) | 1 | |
| 8T1886 | 13 CLIP (TAB) | 1 | |
| 8T1899 | 14 CLIP (SLOT) | 3 | |
| 8T1900 | 15 CLIP (TAB) | 3 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6757 | 19 PLUG-PIPE | 4 | |
| 1140489 | 20 BOLT (M5X0.8X75-MM) | 2 | |
| 1243019 | 21 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1488322 | 22 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488392 | 23 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1783620 | 24 STRAP-DUAL CLAMP | 14 | |
| 2951842 | 25 KIT-ADAPTER | 1 | |
| 2006345 | 26 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 3367700 | 27 CLAMP | 6 | |
| 3438115 | 28 ELBOW AS | 1 | |
| 0307946 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3441950 | 29 CLIP (SLOT) | 1 | |
| 3445674 | 30 NUT (M8X1.25-THD) | 2 | |
| 3510261 | 31 ELBOW AS | 1 | |
| 5P1230 | CONNECTOR | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 3517082 | 32 BRACKET | 1 | |
| 3535127 | 33 ADAPTER AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 0343679 | ADAPTER | 1 | |
| 3535128 | 34 ADAPTER AS | 1 | |
| 6V1230 | ELBOW | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3696883 | 35 ADAPTER AS | 1 | |
| 5P4362 | CONNECTOR | 1 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 3717247 | 36 ADAPTER | 1 | |
| 3850938 | 37 AIR COMPRESSOR GP | 1 | |
| 3855780 | 38 ELBOW AS | 1 | |
| 2T2170 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3940291 | 39 GAUGE-PRESSURE | 1 | |
| 3940292 | 40 REGULATOR GP-AIR PRESSURE | 1 | |
| 3960407 | 41 COUPLER-QUICK DISCONNECT | 1 | |
| 5175132 | 42 TUBE AS | 1 | |
| 5215819 | 43 ELBOW AS | 1 | |
| 6V8350 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2815966 | RING-RETAINING | 1 | |
| 2937312 | ELBOW | 1 | |
| 5388661 | 44 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5400846 | 45 TUBE | 1 | |
| 1488320 | 46 CONNECTOR AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1754429 | 47 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7X7902 | ELBOW | 1 | |
| 2120431 | 48 STUD (M10X1.5X46-MM) | 1 | |
| 2877257 | 49 ELBOW | 1 | |
| 3328556 | 50 CONNECTOR AS | 1 | |
| 1452237 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3441951 | 51 CLIP (TAB) | 1 | |
| 3510270 | 52 ELBOW AS | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 6V5653 | ELBOW (7/8-14-THD) | 1 | |
| 3644568 | 53 STRAP | 2 | |
| 4N9680 | 54 GOVERNOR GP-AIR COMPRESSOR | 1 | |
| 5616827 | 55 HOSE | 1 | |
| 5616828 | 56 HOSE | 1 | |
| 5616829 | 57 HOSE | 1 | |
| 5616830 | 58 HOSE | 1 | |
| 5616834 | 59 TUBE | 1 | |
| 5616835 | 60 HOSE | 1 | |
| 5616838 | 61 BRACKET AS | 1 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 2 | |
| 5851523 | 62 HOSE AS | 1 | |
| 5855911 | 63 HOSE AS | 1 | |
| 5855912 | 64 HOSE AS | 1 | |
| 7K1181 | 65 STRAP-CABLE | 3 | |
| 8M2772 | 66 CLIP (LOOP) | 1 | |
| 8T3647 | 67 BOLT (M8X1.25X80-MM) | 2 | |
| 8T4137 | 68 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4223 | 69 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4908 | 70 BOLT (M8X1.25X25-MM) | 1 |
