System And Components
527-6089 LINES GP-FUELS/N R4H1-UP; R2J1-UP
Group No: 527-6089
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4182 | 1 BOLT (M10X1.5X45-MM) | 1 | |
| 2042281 | 2 STRAP-CABLE | 8 | |
| 7X0818 | 3 BOLT (M8X1.25X45-MM) | 4 | |
| 7X2539 | 4 BOLT (M8X1.25X110-MM) | 2 | |
| 8T6912 | 5 BOLT (M8X1.25X50-MM) | 2 | |
| 3S2093 | 6 STRAP-CABLE | 1 | |
| 5D1026 | 7 CLAMP-BAND | 4 | |
| 5N9204 | 8 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X0579 | 10 WASHER-HARD (8.8X25.5X2-MM THK) | 3 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 5 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4222 | 14 WASHER-PLATED (11X32X2.5-MM THK) | 1 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T6869 | 17 BOLT (M8X1.25X60-MM) | 1 | |
| 1028705 | 18 PLATE (TOP) | 3 | |
| 1336934 | 19 SPACER (11X20X25-MM THK) | 1 | |
| 8V5718 | 20 CLAMP | 6 | |
| 1563616 | 21 CLAMP-HALF | 6 | |
| 1772215 | 22 STRAP-DUAL CLAMP | 3 | |
| 1911782 | 23 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 1911783 | 24 SPACER (8.5X12.7X87.3-MM THK) | 2 | |
| 2609219 | 25 CONNECTOR AS | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2673862 | 26 BRACKET AS | 1 | |
| 1028706 | PLATE AS | 1 | |
| 2815977 | 27 CONNECTOR AS | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2877305 | 28 ELBOW | 1 | |
| 3095131 | 29 PLUG AS | 2 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3196217 | 30 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3353976 | 31 ELBOW AS | 1 | |
| 8T0119 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3432388 | 32 CLIP (LOOP) | 2 | |
| 3445674 | 33 NUT (M8X1.25-THD) | 2 | |
| 3985596 | 34 PLUG AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3985601 | 35 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 4216208 | 36 PLUG AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603695 | PLUG | 1 | |
| 4391804 | 37 VALVE AS-BALL | 3 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3510266 | VALVE-BALL | 1 | |
| 4675344 | 38 MOUNT | 6 | |
| 5127778 | 39 BRACKET AS | 1 | |
| 1028706 | PLATE AS | 1 | |
| 5280256 | 40 TIE-CABLE | 2 | |
| 1488370 | 41 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 2233490 | 42 CLIP | 3 | |
| 2815981 | 43 ELBOW AS | 1 | |
| 6V8722 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3270325 | 44 STRAP-CABLE | 3 | |
| 3341073 | 45 CLAMP | 3 | |
| 3523964 | 46 CLIP (LADDER) | 1 | |
| 4343926 | 47 BASE GP-FUEL FILTER | 1 | |
| 4672847 | 48 PUMP GP-FUEL PRIMING (PRIMARY FILTER) | 1 | |
| 4883746 | 49 PLATE | 3 | |
| 5276165 | 50 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 5276185 | 51 HOSE AS | 1 | |
| 5276186 | 52 HOSE AS | 1 | |
| 5276187 | 53 HOSE AS | 1 | |
| 5660072 | 54 ADAPTER AS | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2815871 | ADAPTER | 1 | |
| 5660073 | 55 ELBOW AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3717242 | ADAPTER-ELBOW | 1 | |
| 5661865 | 56 ADAPTER AS | 2 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4632161 | ADAPTER | 1 | |
| 5834686 | 57 BRACKET AS | 1 | |
| 5837900 | 58 HOSE AS | 1 | |
| 6D4244 | 59 CLIP (LOOP) | 1 | |
| 8T4183 | 60 BOLT (M12X1.75X40-MM) | 1 | |
| 8T4195 | 61 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 62 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4908 | 63 BOLT (M8X1.25X25-MM) | 2 | |
| 3478646 | 64 HOSE (120-CM) | ||
| 3478647 | 65 HOSE (865-CM) |
