System And Components
1C-4209 SENSOR GP-GRADES/N 5XC138-UP
Group No: 1C-4209
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0820796 | 1 COLLAR | 1 | |
| 9N9465 | 2 HOLDER | 1 | |
| 9N9466 | 3 KNOB | 1 | |
| 9N7305 | 4 SPRING | 2 | |
| 8C1636 | 5 BRACKET | 1 | |
| 1C4486 | 6 CLAMP | 1 | |
| 9N7035 | 7 CLAMP | 1 | |
| 8C0956 | 8 BRACKET | 1 | |
| 5S7349 | 9 BOLT (1/4-20X0.5-IN) | 2 | |
| 9B7237 | 10 BOLT (3/8-16X1.25-IN) | 3 | |
| 4M6425 | 11 BOLT (5/16-18X1-IN) | 2 | |
| 8T8911 | 12 BOLT (5/16-18X2-IN) | 2 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 1 | |
| 8T4039 | 14 COUNTERWEIGHT GP | 1 | |
| 8T2501 | 15 BOLT (3/8-16X2-IN) | 2 | |
| 8T8919 | 16 BOLT (1/2-13X1.75-IN) | 1 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 2 | |
| 6V8188 | 18 NUT (1/2-13-THD) | 2 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 3K8282 | 22 PIN-SPRING | 1 | |
| 3K6060 | 23 LOCKNUT (3/8-16-THD) | 2 | |
| 8T4037 | 24 MOUNT AS-SENSOR | 1 | |
| 8T4205 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 0869815 | 26 WAND AS | 1 | |
| 0775167 | SPRING | 1 | |
| 1C4590 | 27 TUBE | 1 | |
| 8T4552 | 28 ADAPTER | 1 |
