System And Components
122-8962 AIR COMPRESSOR GPS/N 7XD14-UP
Group No: 122-8962
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6K1972 | 1 ELBOW-FLARED | 1 | |
| 0616750 | 2 HOSE AS | 1 | |
| 2N1287 | 3 ELBOW-FLARED | 1 | |
| 2N3378 | 4 ELBOW-FLARED | 2 | |
| 1228966 | 5 AIR COMPRESSOR GP | 1 | |
| 4N6708 | 6 PULLEY-AIR COMPRESSOR | 1 | |
| 9M5082 | 7 STUD-TAPERLOCK | 4 | |
| 4S9191 | 8 WASHER (12X22.5X5-MM THK) | 4 | |
| 3S1546 | 9 NUT-FULL (7/16-14-THD) | 4 | |
| 6N9042 | 10 GASKET | 1 | |
| 4N6662 | 11 PLATE | 1 | |
| 9N1828 | 12 GASKET | 1 | |
| 7L7262 | 13 ELBOW-FLARED | 1 | |
| 0T0772 | 14 BOLT (7/16-14X1.5-IN) | 4 | |
| 9N6473 | 15 BRACKET-LIFTING | 1 | |
| 4F8965 | 16 BOLT (7/16-14X1.125-IN) | 2 | |
| 5P8244 | 17 WASHER-HARD (12X22.5X2.5-MM THK) | 6 | |
| 1H5166 | 18 CLIP | 1 | |
| 2N1343 | 19 HOSE AS | 1 | |
| 3B4618 | 20 PIN-COTTER | 1 | |
| 5P4295 | 21 CLIP | 1 | |
| 3R5387 | 22 CONNECTOR | 1 | |
| 4N8470 | 23 HOSE AS | 1 | |
| 8T6764 | 24 PLUG-PIPE (1/8-27-THD) | 1 | |
| 5P8248 | 25 WASHER-HARD (20X36.5X3.5-MM THK) | 1 |
