System And Components
535-8524 LINES GP-PILOTS/N RCY1-UP
Group No: 535-8524
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5357052 | 1 BRACKET | 1 | |
| 6V5535 | 2 TEE-UNION | 1 | |
| 7K1181 | 3 STRAP-CABLE | 2 | |
| 8T2909 | 4 UNION-ADAPTER | 1 | |
| 0307936 | 5 CONNECTOR | 1 | |
| 2235993 | 6 WASHER (6X12X1-MM THK) | 4 | |
| 2258051 | 7 HOSE AS | 1 | |
| 2493847 | 8 BOLT (1/4-20X1-IN) | 4 | |
| 2493853 | 9 HOSE AS | 1 | |
| 2493858 | 10 HOSE AS | 1 | |
| 3203065 | 11 SENSOR GP-PRESSURE (PILOT) | 1 | |
| 5025349 | 12 CONTROL GP-PILOT OPERATED HYD | 1 | |
| 5357100 | 13 HOSE AS | 1 | |
| 5362598 | 14 HOSE AS | 1 | |
| 5412141 | 15 HOSE AS | 1 | |
| 5412142 | 16 HOSE AS | 1 | |
| 0307947 | 17 ADAPTER-ELBOW | 4 | |
| 0S1617 | 18 BOLT (5/16-18X0.75-IN) | 2 | |
| 2P1279 | 19 LOCKNUT (9/16-18-THD) | 1 | |
| 2P7214 | 20 ADAPTER-ELBOW | 5 | |
| 2R6806 | 21 CONNECTOR | 2 | |
| 3J1907 | 22 SEAL-O-RING | 13 | |
| 5M3062 | 23 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P1075 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 5P2369 | 25 CLIP (LOOP) | 1 | |
| 9M1974 | 26 WASHER-HARD (8.8X16X2-MM THK) | 2 |
