System And Components
425-3746 PANEL GP-ELECTRICAL -BARRIER CONTROLPART OF 468-4602 INSTALLATION GP-FIELD, 440-0293 WIRING GP-PANEL
Group No: 425-3746
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 0898034 | 2 SCREW-BUTTON HEAD | 2 | |
| 1005805 | 3 CAP-RECEPTACLE (3-PIN) | 1 | |
| 2264038 | 4 TAPE-REFLECTIVE | 3 | |
| 2459167 | 5 NUT (M4X0.7X5.5-MM) | 4 | |
| 2459168 | 6 WASHER (4.7X9X0.8-MM THK) | 13 | |
| 3033844 | 7 ISOLATOR | 1 | |
| 3033859 | 8 COVER-BOX | 1 | |
| 3055121 | 10 CLAMP | 8 | |
| 3055122 | 11 TERMINAL | 4 | |
| 3055128 | 12 TERMINAL | 8 | |
| 3162769 | 13 NUT (M3X0.5-THD) | 8 | |
| 3187611 | 14 MODULE-INPUT | 1 | |
| 3187612 | 15 MODULE (TERMINAL, ELECTRONIC MODULE) | 2 | |
| 3187613 | 16 MODULE (TERMINAL, POWER MODULE) | 1 | |
| 3214420 | 17 CONVERTER | 1 | |
| 3214471 | 18 CIRCUIT BREAKER (6-AMPERE) | 7 | |
| 3214472 | 19 MODULE-INTERFACE | 1 | |
| 3214473 | 20 MODULE-POWER | 1 | |
| 5497288 | 21 RELAY (2-AMPERE)(SIRIUS) | 1 | |
| 3214477 | 22 COVER | 1 | |
| 3214527 | 23 LINK | 6 | |
| 3214532 | 24 SEAL | 1 | |
| 3234689 | 25 FILM-WARNING (SHOCK, ELECTROCUTION HAZARD) | 1 | |
| 3241840 | 26 MODULE | 1 | |
| 3241944 | 27 CABLE AS | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 3343108 | 28 FILM-INSTRUCTION (AREA ISOLATION SYSTEM) | 1 | |
| 3343109 | 29 FILM-INSTRUCTION (ISOLATION SYSTEM RESET) | 1 | |
| 3343110 | 30 FILM-INSTRUCTION (ISOLATION SYSTEM SHUTDOWN) | 1 | |
| 3360199 | 31 FILM-IDENTIFICATION (AREA ISOLATION SYSTEM) | 1 | |
| 3386733 | 32 TERMINAL | 10 | |
| 3661743 | 33 CAP | 6 | |
| 4404394 | 46 SWITCH-PUSH (GREEN) | 1 | |
| 4404395 | 47 HOLDER | 1 | |
| 4404398 | 48 BLOCK AS (LIGHT) | 1 | |
| 4426213 | 49 BLOCK-CONTACT | 2 | |
| 4426217 | 50 HOLDER | 1 | |
| 4426218 | 51 BLOCK-CONTACT | 1 | |
| 4618745 | 52 COVER AS | 1 | |
| 4773235 | 53 ENCLOSURE | 1 | |
| 4773236 | 54 PLATE AS | 1 | |
| 4773237 | 55 PLATE | 1 | |
| 4773238 | 56 MODULE | 2 | |
| 4773239 | 57 FILM-IDENTIFICATION (ELECTRICAL PANEL) | 1 | |
| 4773240 | 58 FILM-IDENTIFICATION (ELECTRICAL PANEL) | 1 | |
| 4773241 | 59 CONNECTOR | 2 | |
| 4773242 | 60 CONNECTOR | 2 | |
| 4773243 | 61 VALVE | 1 | |
| 4773244 | 62 INDICATOR (SHUTDOWN) | 4 | |
| 4792117 | 63 FILM-IDENTIFICATION (ELECTRICAL PANEL) | 1 | |
| 4821855 | 64 SWITCH-STOP (EMERGENCY) | 1 | |
| 4821856 | 65 BLOCK AS | 1 | |
| 4836570 | 66 BLOCK | 1 | |
| 0950723 | 67 SCREW-SPECIAL (M3X0.5X10-MM) | 4 | |
| 0960192 | 68 LOCKWASHER | 3 | |
| 0966166 | 69 WASHER-HARD (4.5X9X1-MM THK) | 12 | |
| 0996418 | 70 NUT (M6X1-THD) | 4 | |
| 1209027 | 71 SCREW-PAN HEAD (M3X0.5X16-MM) | 4 | |
| 1504086 | 72 SCREW (M4X0.7X16-MM) | 4 | |
| 1554098 | 73 SCREW-BUTTON HEAD (M3X0.5X1-MM) | 6 | |
| 2235993 | 74 WASHER (6X12X1-MM THK) | 6 | |
| 2606723 | 75 BOLT-SOCKET HEAD (M6X1X30-MM) | 1 | |
| 3033861 | 76 LATCH | 1 | |
| 3132865 | 77 TERMINAL | 3 | |
| 3132867 | 78 TERMINAL | 7 | |
| 3162770 | 79 WASHER (3X6X0.8-MM THK) | 8 | |
| 3214503 | 80 COVER | 2 | |
| 3214528 | 81 RELAY (24-VDC) | 2 | |
| 3911756 | 83 WASHER (3.3X9.5X1.6-MM THK) | 6 | |
| 3B4503 | 84 LOCKWASHER | 6 | |
| 5C2874 | 85 NUT (M5X0.8-THD) | 1 | |
| 5C2890 | 86 NUT (M6X1-THD) | 2 | |
| 5C7261 | 87 NUT (M8X1.25-THD) | 4 | |
| 5W8686 | 88 WASHER (6X13X2-MM THK) | 4 | |
| 8T4189 | 89 BOLT (M8X1.25X20-MM) | 4 | |
| 6V9673 | 90 SCREW-MACHINE (M5X0.8X12-MM) | 6 | |
| 7Y5288 | 91 SCREW-PAN HEAD (4X10-MM) | 4 | |
| 8C3131 | 92 SEAL-O-RING | 3 | |
| 8T0337 | 93 SCREW-MACHINE (M4X0.7X12-MM) | 13 | |
| 8T2226 | 94 SCREW-MACHINE (M5X0.8X10-MM) | 3 | |
| 8T2659 | 95 LOCKNUT (M4X0.7-THD) | 8 | |
| 8T4205 | 96 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 97 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X4813 | 98 RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 9X8256 | 99 WASHER (6.6X12X2-MM THK) | 1 | |
| 9X8267 | 100 WASHER (6.6X12X2-MM THK) | 1 | |
| 3187724 | 101 DUCT (0.3-M EACH) | ||
| 3187724 | 101A DUCT (0.2-M EACH) | ||
| 3187723 | 102 RAIL (0.3-M EACH) | ||
| 3442356 | 103 FILM-IDENTIFICATION (CE MARK) | 1 |
