System And Components
278-1505 COVER GP-CAB -OPEN ROPSS/N LJB1192-1453
Group No: 278-1505
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2457964 | 1 COVER | 1 | |
| 2457965 | 2 COVER | 1 | |
| 2457966 | 3 COVER | 1 | |
| 2375004 | 4 SCREW (1/4-20X.75-IN) | 25 | |
| 2457967 | 5 COVER | 1 | |
| 2457968 | 6 COVER | 1 | |
| 2457969 | 7 COVER | 1 | |
| 2457970 | 8 COVER | 1 | |
| 9B7237 | 9 BOLT (3/8-16X1.25-IN) | 2 | |
| 2457980 | 10 WASHER (7.1X15.7X1.3- MM THK) | 5 | |
| 2170375 | 11 COVER | 1 | |
| 2479556 | 12 COVER AS | 1 | |
| 1160118 | CLIP | 1 | |
| 4M0061 | 13 BOLT (5/16-18X0.75-IN) | 2 | |
| 2359828 | 14 CHAIN (1-M) | ||
| 8C3121 | 15 BOLT (5/16-18X1.5-IN) | 3 | |
| 0314155 | 16 LOCKNUT (5/16-18-THD) | 3 | |
| 3E4352 | 17 WASHER-HARD (8.8X20.5X2.5-MM THK) | 6 | |
| 2457973 | 18 PLUG | 1 | |
| 2457975 | 19 PLUG | 2 | |
| 8T4896 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 5S7379 | 21 BOLT (3/8-16X0.875-IN) | 10 | |
| 2457976 | 22 COVER | 1 | |
| 5M3062 | 23 BOLT (3/8-16X0.75-IN) | 1 | |
| 2457977 | 24 COVER | 1 | |
| 5P4116 | 25 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 2780265 | 26 COVER | 1 | |
| 6V9483 | 27 BOLT (1/4-20X0.5-IN) | 3 | |
| 8T8908 | 28 BOLT (1/4-20X1-IN) | 5 | |
| 2207208 | 29 NUT (1/4-20-THD) | 5 | |
| 2235993 | 30 WASHER (6X12X1-MM THK) | 3 |
