System And Components
456-2116 PANEL GP-INSTRUMENT -MONITOR, SWITCHS/N JLK1203-1203; JLK1208-UP
Group No: 456-2116
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6328 | 1 ALARM GP (24-VOLT) | 1 | |
| 5P8500 | 2 KEY | 1 | |
| 4678535 | 3 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1297184 | 4 FILM-INSTRUCTION (ENGINE START) | 1 | |
| 2306374 | 5 CAP | 4 | |
| 2306377 | 6 CAP | 4 | |
| 2452181 | 7 RECEPTACLE | 1 | |
| 2510651 | 8 FILM-IDENTIFICATION (WARNING INDICATOR) | 1 | |
| 2524503 | 9 CONTROL GP-UNPROGRAMMED (CATERPILLAR MONITORING SYSTEM) | 1 | |
| 9X4711 | CAP | 1 | |
| 4445927 | 10 PANEL GP-SWITCH | 1 | |
| 1305300 | 11 CLIP | 3 | |
| 2235993 | 12 WASHER (6X12X1-MM THK) | 4 | |
| 2306375 | 13 BOLT (M5X0.8X12-MM) | 4 | |
| 2306376 | 14 WASHER-SPECIAL (5.5X10X1-MM THK) | 4 | |
| 2307371 | 15 BOLT (M6X1X16-MM) | 4 | |
| 6V0292 | 16 PLUG | 1 | |
| 9X2045 | 17 SCREW-TRUSS HEAD (M6X1X20-MM) | 1 |
