System And Components
379-9992 PANEL GP-SWITCHS/N XBR1-UP
Group No: 379-9992
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1V6491 | 1 BOOT-SWITCH | 4 | |
| 2D8009 | 2 SEAL-O-RING | 1 | |
| 4J0527 | 3 SEAL-O-RING | 1 | |
| 3166409 | 4 LAMP AS (10 TO 32-VOLT) | 1 | |
| 5P5694 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 1165271 | 5 LAMP (24-VOLT, YELLOW)(AMBER) | 1 | |
| 2287150 | 6 PANEL | 1 | |
| 9X6258 | 7 SCREW-MACHINE (6-32X0.5-IN) | 4 | |
| 2306374 | 8 CAP | 4 | |
| 2452166 | 9 BLOCK | 1 | |
| 2452167 | 10 BLOCK | 2 | |
| 1357242 | 11 SCREW-SELF-TAPPING (M5X2.3X18.8-MM) | 15 | |
| 3137185 | 12 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 3799993 | 13 HARNESS AS-SWITCH | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 33 | |
| 8T8737 | PLUG-SEAL | 7 | |
| 9X7148 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 2235993 | 14 WASHER (6X12X1-MM THK) | 4 | |
| 2307371 | 15 BOLT (M6X1X16-MM) | 4 | |
| 4J5477 | 16 SEAL-O-RING | 3 | |
| 6V1193 | 17 SCREW-HEX SOCKET (3/8-16X0.625-IN) | 3 | |
| 7N8001 | 18 SWITCH GP-TOGGLE (CRANK OVERRIDE) | 1 | |
| 7T3946 | 19 SWITCH GP-TOGGLE (FAN BLOWER SPEED) | 2 | |
| 3L8187 | LOCKWASHER | 6 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 6 | |
| 8D2676 | 20 SWITCH AS-TOGGLE (SINGLE POLE)(CONTROL SELECT) | 1 | |
| 8T4138 | 21 BOLT (M6X1X20-MM) | 8 | |
| 8T4205 | 22 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 2287151 | PLATE-COVER | 1 |
