System And Components
489-3442 LINES GP-SECONDARY STEERINGS/N ZLK1-UP
Group No: 489-3442
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6429 | 1 SWITCH AS-FLOW (SECONDARY STEERING) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 9X1813 | SLEEVE (20-CM) | ||
| 2152141 | 2 COUPLING-ELBOW | 1 | |
| 2491042 | 3 MANIFOLD | 1 | |
| 2491043 | 4 HOSE AS | 1 | |
| 3214622 | 5 MANIFOLD | 1 | |
| 3V8497 | BLOCK-MANIFOLD | 1 | |
| 4620843 | 6 STEM | 1 | |
| 0307951 | 7 ELBOW-FLARED | 2 | |
| 1P3705 | 8 SEAL-RECTANGULAR | 1 | |
| 1P4579 | 9 FLANGE-HALF | 4 | |
| 3K0360 | 10 SEAL-O-RING | 1 | |
| 4J0523 | 11 SEAL-O-RING | 1 | |
| 4J0524 | 12 SEAL-O-RING | 2 | |
| 7M8485 | 13 SEAL-O-RING | 4 | |
| 7X0328 | 14 BOLT (1/2-13X3.5-IN) | 4 | |
| 8T3957 | 15 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 2 | |
| 8T4184 | 16 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4835 | 18 BOLT (1/2-13X2-IN) | 4 | |
| 8T6703 | 19 CLAMP-HOSE | 4 | |
| 9S4181 | 20 PLUG (1-5/16-12-THD) | 2 | |
| 5P1291 | 21 HOSE (18-CM) |
