System And Components
303-4001 CYLINDER GP-HYDRAULICS/N ZLK1-UP
Group No: 303-4001
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1869711 | 1 CYLINDER AS-LIFT | 1 | |
| 1V7001 | 1A BUSHING | 1 | |
| 2979599 | CYLINDER AS-LIFT | 1 | |
| 5P8112 | 2 GROMMET | 1 | |
| 2813694 | 3 ROD AS-HYDRAULIC CYLINDER | 1 | |
| 2881363 | 4 HEAD-CYLINDER | 1 | |
| 5S7349 | 5 BOLT (1/4-20X0.5-IN) | 4 | |
| 6J6478 | 6 WASHER (0.28X0.63X0.13-IN THK) | 4 | |
| 4J8734 | 7 LOCKNUT (2-3/4-12-THD) | 1 | |
| 2066955 | 8 SEAL AS | 1 | |
| 2067001 | 9 RING-WEAR | 1 | |
| 2191159 | 10 PISTON | 1 | |
| 3033489 | 11 SEAL | 1 | |
| 3033491 | 12 SEAL | 1 | |
| 3033492 | 13 SEAL | 1 | |
| 3033495 | 14 RING | 1 | |
| 5P2235 | 15 SEAL-O-RING | 1 | |
| 5M0544 | 16 BOLT (1-1/8-7X4.5-IN) | 2 | |
| 3S1349 | 17 WASHER-HARD (31X52.5X6-MM THK) | 8 | |
| 3N1614 | 18 BOLT (1-1/8-7X4-IN) | 6 | |
| 1418610 | 20 PLATE | 1 | |
| 5S7383 | 21 BOLT (3/8-16X1.75-IN) | 2 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3029176 | KIT-SEAL (HYDRAULIC CYLINDER) | 1 |
