System And Components
174-4700 CYLINDER GP-TILTS/N ZLK1-UP
Group No: 174-4700
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1013672 | 1 BOLT (M36X4X120-MM) | 6 | |
| 1470169 | 2 BOLT (M36X4X150-MM) | 2 | |
| 1577244 | 3 RING-BACKUP | 1 | |
| 1647477 | 4 HEAD AS | 1 | |
| 2253291 | SEAL-WIPER | 1 | |
| 1672225 | 5 SEAL AS-BUFFER | 1 | |
| 1672344 | 6 SEAL-U-CUP | 1 | |
| 1868510 | 7 RING-RETAINING | 1 | |
| 1868713 | 8 CUSHION | 1 | |
| 1868939 | 9 ROD AS-HYDRAULIC CYLINDER | 1 | |
| 1V5635 | 9A BUSHING | 1 | |
| 5S0003 | NUT (5/16-18-THD) | 2 | |
| 1868940 | 10 BARREL AS | 1 | |
| 1V5635 | 10A BUSHING | 1 | |
| 3B8489 | FITTING-GREASE (1/8-27 PTF) | 1 | |
| 7K9220 | SEAL-LIP TYPE | 2 | |
| 1868941 | 11 PISTON | 1 | |
| 2253291 | 12 SEAL-WIPER | 1 | |
| 3B8488 | 13 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3G5022 | 14 LOCKNUT (4 1/2-12-THD) | 1 | |
| 3S6162 | 15 WASHER-HARD (40.5X67X6-MM THK) | 8 | |
| 5P2236 | 16 SEAL-O-RING | 1 | |
| 6V4463 | 17 BOLT-LOCKING (1/2-13X1.375-IN) | 6 | |
| 6V5215 | 18 BOLT (M8X1.25X16-MM) | 4 | |
| 7S6369 | 19 WASHER (0.344X0.75X0.188-IN THK) | 4 | |
| 8L9241 | 20 SEAL-O-RING | 1 | |
| 8T1796 | 21 SEAL AS | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 9X7420 | 23 RING-WEAR | 1 | |
| 9J1159 | 24 RING-WEAR (260.3-MM ID) | 1 | |
| 1869285 | KIT-SEAL (STANDARD) | 1 | |
| 2130942 | KIT-SEAL (0.03-IN OS) | 1 |
