System And Components
426-9993 LINES GP-RIDE CONTROLS/N ZLK1-UP
Group No: 426-9993
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4T5541 | 1 VALVE GP-DIVERTER | 1 | |
| 6C7139 | 2 MANIFOLD | 1 | |
| 1665469 | 3 BLOCK-HYDRAULIC | 2 | |
| 6E4701 | 4 VALVE GP-CHECK | 1 | |
| 3187597 | 5 VALVE GP-RELIEF | 1 | |
| 7X0331 | 6 BOLT (1/2-13X4.25-IN) | 2 | |
| 8T4223 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 2449524 | 8 HOSE AS | 1 | |
| 2494555 | 9 HOSE AS | 1 | |
| 2494556 | 10 HOSE AS | 1 | |
| 4256068 | 11 HOSE AS | 1 | |
| 3K0360 | 12 SEAL-O-RING | 2 | |
| 0307955 | 13 TEE-FLARED | 1 | |
| 5P2369 | 14 CLIP (LOOP) | 1 | |
| 2494558 | 15 HOSE AS | 1 | |
| 2494559 | 16 HOSE AS | 1 | |
| 2494560 | 17 HOSE AS | 1 | |
| 2494561 | 18 HOSE AS | 1 | |
| 5H4019 | 19 COVER | 2 | |
| 4J0520 | 20 SEAL-O-RING | 10 | |
| 5S7382 | 21 BOLT (3/8-16X1.375-IN) | 8 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 5P7468 | 23 CLIP (SLOT) | 1 | |
| 5P7469 | 24 CLIP (TAB) | 1 | |
| 5P8444 | 25 GROMMET (37-MM ID) | 1 | |
| 8T8919 | 26 BOLT (1/2-13X1.75-IN) | 2 | |
| 1635832 | 27 TIE-CABLE | 3 | |
| 1P4577 | 28 FLANGE-HALF | 12 | |
| 8T9101 | 29 BOLT (3/8-16X2.75-IN) | 8 | |
| 9S4181 | 30 PLUG (1-5/16-12-THD) | 1 | |
| 9S4185 | 31 PLUG (3/4-16-THD) | 1 | |
| 4I0899 | 32 FITTING | 1 | |
| 8T8915 | 33 BOLT (3/8-16X3.25-IN) | 8 | |
| 8C3051 | 34 ADAPTER | 1 | |
| 3J7354 | 35 SEAL-O-RING | 2 | |
| 7M8485 | 36 SEAL-O-RING | 3 | |
| 2P7212 | 37 ELBOW-UNION | 1 | |
| 3618554 | 38 ACCUMULATOR GP (CHARGED) | 1 | |
| 2R6806 | 40 CONNECTOR | 3 | |
| 2149232 | 41 CLAMP | 1 | |
| 8S2331 | 42 BOLT-12 POINT HEAD (5/8-11X2-IN) | 1 | |
| 8T4122 | 43 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 0307951 | 45 ELBOW-FLARED | 1 | |
| 0S1593 | 46 BOLT (1/2-20X1.25-IN) | 3 | |
| 2935094 | 47 HOSE AS | 1 | |
| 2P1279 | 48 LOCKNUT (9/16-18-THD) | 1 | |
| 3J1907 | 49 SEAL-O-RING | 6 | |
| 9S4191 | 50 PLUG (9/16-18-THD) | 2 | |
| 5S7379 | 51 BOLT (3/8-16X0.875-IN) | 1 | |
| 5P1075 | 52 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 0054362 | 53 ELBOW | 1 | |
| 0307946 | 54 ELBOW | 1 | |
| 1602242 | 63 SLEEVE-ABRASION (26.8-IN) |
