System And Components
432-1625 ADJUSTER GP-HEIGHT -LHPART OF 450-4716 ADJUSTER GP-HEIGHT
Group No: 432-1625
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3084793 | 1 ROD END (RH) | 1 | |
| 3084796 | 2 WASHER (25.5X35X4.5-MM THK) | 2 | |
| 4939244 | 3 ROD | 1 | |
| 4959830 | 4 WRENCH-RATCHET | 1 | |
| 3126351 | 5 RACE-BEARING | 2 | |
| 3126352 | 6 RACE-BEARING | 2 | |
| 3126353 | 7 BEARING-SELF-ALIGNING | 2 | |
| 4445390 | 8 NUT (M30X2X50.5-MM) | 1 | |
| 4445391 | 9 ADJUSTER AS | 1 | |
| 4254127 | 10 PIN | 1 | |
| 4321615 | 11 GUIDE AS (LH) | 1 | |
| 4321616 | 12 GUIDE | 1 | |
| 4321618 | 13 GUIDE AS | 1 | |
| 4321614 | GUIDE | 1 | |
| 4489774 | 14 PIN | 2 | |
| 4321620 | 15 SPACER (21X37X4-MM THK) | 2 | |
| 4321622 | 16 SPACER (15X20X23-MM THK) | 1 | |
| 4321629 | 17 PLATE-INDICATOR | 1 | |
| 2R1230 | 18 RING-RETAINING | 2 | |
| 3084794 | 19 ROD END (LH) | 1 | |
| 5P1076 | 20 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 6V5200 | 21 RING-RETAINING | 2 | |
| 7J5925 | 22 PIN-COTTER | 1 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 1 | |
| 7Y1537 | 24 LOCKNUT (M20X2.5-THD) | 2 | |
| 8T0389 | 25 LOCKNUT (M10X1.5-THD) | 1 | |
| 8T4123 | 26 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T8549 | 27 LOCKNUT (M12X1.75-THD) | 1 | |
| 8T4970 | 28 BOLT (M6X1X14-MM) | 2 | |
| 8T5436 | 29 BOLT (M10X1.5X130-MM) | 1 | |
| 9X8256 | 30 WASHER (6.6X12X2-MM THK) | 2 |
