System And Components
428-4927 ADJUSTER GP-HEIGHTPART OF 453-6578 SCREED AR
Group No: 428-4927
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8488 | 1 FITTING-GREASE (1/8-27 PTF) | 4 | |
| 3B8485 | 2 ELBOW | 8 | |
| 5401543 | 3 PLATE | 8 | |
| 3646874 | 4 PLATE | 8 | |
| 3646875 | 5 SEAL-RUBBER | 8 | |
| 3907798 | 6 BALL JOINT AS | 8 | |
| 0058639 | 6A BEARING-ALIGNING | 1 | |
| 4253516 | 7 PIN | 8 | |
| 4373760 | 8 CHAIN GP-SCREED | 4 | |
| 1022687 | LINK-CONNECTING | 1 | |
| 1959533 | LINK-OFFSET | 1 | |
| 5733164 | 9 SHAFT AS-REAR | 4 | |
| 4374460 | 10 PIN | 4 | |
| 4374461 | 11 BLOCK | 4 | |
| 5733165 | 12 SHAFT AS-FRONT | 4 | |
| 4388556 | 13 BRACKET | 2 | |
| 4947645 | 14 INDICATOR | 2 | |
| 4388558 | 15 BRACKET | 2 | |
| 4947646 | 16 INDICATOR | 2 | |
| 1907971 | 17 WASHER-HARD (11X64X6-MM THK) | 4 | |
| 1K6985 | 18 RING-RETAINING | 4 | |
| 2088469 | 19 LOCKNUT (M6X1-THD) | 8 | |
| 5C9553 | 20 BOLT (M6X1X16-MM) | 16 | |
| 5P4115 | 21 WASHER-HARD (7.2X19X2-MM THK) | 16 | |
| 5P8837 | 22 LOCK PIN | 8 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 24 | |
| 7X7888 | 24 BOLT (M6X1X90-MM) | 8 | |
| 8T4136 | 25 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4140 | 26 BOLT (M16X2X60-MM) | 8 | |
| 8T4185 | 28 BOLT (M10X1.5X50-MM) | 24 | |
| 9M1328 | 29 BEARING-SELF-ALIGNING | 4 | |
| 9X8256 | 30 WASHER (6.6X12X2-MM THK) | 16 | |
| 9X8257 | 31 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 4M8973 | 32 ELBOW | 4 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4191 | 34 BOLT (M10X1.5X16-MM) | 4 | |
| 1488320 | 35 CONNECTOR AS | 4 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1716727 | 36 ADAPTER AS | 4 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T4128 | ADAPTER | 1 | |
| 3232949 | 37 CLIP (LOOP) | 4 | |
| 5667214 | 38 TUBE AS | 4 | |
| 5401541 | 39 WASHER-THRUST (35X51X3-MM THK) | 8 | |
| 5401542 | 40 WASHER-THRUST | 8 |
