System And Components
126-8216 AIR COMPRESSOR GPS/N NME1-UP
Group No: 126-8216
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5106 | 1 BRACKET | 1 | |
| 7C3179 | 2 GEAR (50-TEETH) | 1 | |
| 1359819 | 3 SEAL-INTEGRAL | 1 | |
| 1494915 | 4 AIR COMPRESSOR GP | 1 | |
| 2001196 | 5 HOSE AS | 1 | |
| 0617538 | 6 SEAL-O-RING | 1 | |
| 2N1287 | 7 ELBOW-FLARED | 1 | |
| 5P8245 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6B6682 | 9 NUT-FULL (3/4-16-THD) | 1 | |
| 6D3479 | 10 CLIP (LOOP)(TAB) | 1 | |
| 6V5696 | 11 BOLT (M12X1.75X80-MM) | 2 | |
| 7X0521 | 12 WASHER-HARD (20X36.5X5-MM THK) | 1 | |
| 8C6866 | 13 CONNECTOR | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 2 | |
| 8T6764 | 17 PLUG-PIPE (1/8-27-THD) | 1 |
