Assembly
100%

124-2580 LINES GP-CHASSISS/N 3PN784-2026

Group No: 124-2580
Part NumberPart NameQty
11763841 VALVE GP-COMPENSATING1
16971242 HOSE AS1
16971253 HOSE AS1
12178994 HOSE AS1
12179005 HOSE AS1
12390816 HOSE AS4
6V89817 ELBOW1
6V8398SEAL-O-RING2
6V86398 CONNECTOR3
3K0360SEAL-O-RING3
6V8398SEAL-O-RING3
6V87239 ELBOW4
3K0360SEAL-O-RING4
6V8397SEAL-O-RING4
6V899510 UNION (STRAIGHT)1
6V8398SEAL-O-RING2
6V916911 NUT (13/16-16-THD)2
6V918912 LOCKNUT (M8X1.25-THD)2
7X253813 BOLT (M8X1.25X100-MM)2
8I580114 PLATE-SUPPORT1
8I581115 PLATE SUPPORT1
8T418916 BOLT (M8X1.25X20-MM)2
8T422417 WASHER-HARD (8.8X16X2-MM THK)4
081575918 CLAMP AS2
098568719 TEE2
3K0360SEAL-O-RING2
6V8397SEAL-O-RING4
6V863720 CONNECTOR2
3D2824SEAL-O-RING2
6V9746SEAL-O-RING2
6V985121 ELBOW2
6V8398SEAL-O-RING2
6V862522 ELBOW1
3K0360SEAL-O-RING1
6V8398SEAL-O-RING1
