Assembly
100%

450-9948 TRIM GP-CABS/N DJB1-483; MLH1-842; MJR1-270; GAT1-257

Group No: 450-9948
Part NumberPart NameQty
24971951 SCREW-PAN HEAD (M3.5X1.57X16-MM)4
38840632 SCREW (M6X1X20-MM)1
32356293 ELBOW-HOSE3
32372284 NOZZLE (LINEAR)2
16221655 BOLT-SOCKET HEAD (M4X0.7X16-MM)2
34753736 SCREW-PAN HEAD2
34175907 NUT (M6X1-THD)19
32372658 CLAMP10
22026089 HOLDER-FLIP CHART1
315381610 COVER1
315381711 COVER1
315382012 COVER1
315384913 HOSE2
315390115 WASHER (6.2X20X5-MM THK)6
318043716 WASHER-SPECIAL12
329433817 COVER AS (REAR, RH SIDE)1
459518818 CONNECTOR3
459537119 VENT4
112848920 SCREW (M6X1X20-MM)18
442859921 TRIM GP-CAB1
