461-9742 MOUNTING GP-ENGINE & XMSNS/N THG1-UP; THH1-UP; THL1-UP

Group No: 461-9742
Part NumberPart NameQty
29770151 BOLT (5/16-18X2-IN)6
29770322 SCREW (3/8-16X1.25-IN)2
7X03543 BOLT (5/8-11X4.5-IN)2
30385594 SCREW (M16X2X45-MM)4
29770985 SCREW (M10X1.5X35-MM)10
8T41926 BOLT (M12X1.75X25-MM)2
7X04487 NUT (5/8-11-THD)2
29873658 WASHER (10.2X20.6X1.7-MM THK)2
8T41219 WASHER-HARD (11X21X2.5-MM THK)10
8T422310 WASHER-HARD (13.5X25.5X3-MM THK)2
9X825711 WASHER (17.5X30X3.5-MM THK)4
303478812 WASHER (0.34X0.69X0.09-IN THK)6
437765313 WASHER (16.7X71.4X4.5-MM THK)2
298736814 WASHER (0.66X1.31X0.095-IN THK)2
389344115 BRACKET AS1
437765616 MOUNT2
389355217 BRACKET AS-FUEL FILTER1
