Assembly
100%

465-2230 MOUNTING GP-ENGINE & XMSNS/N MDD1-UP; SXM1-UP

Group No: 465-2230
Part NumberPart NameQty
29770151 BOLT (5/16-18X2-IN)6
29770322 SCREW (3/8-16X1.25-IN)2
7X03543 BOLT (5/8-11X4.5-IN)2
8T49564 BOLT (M12X1.75X35-MM)4
30385595 SCREW (M16X2X45-MM)6
8T41866 BOLT (M10X1.5X40-MM)10
7X04487 NUT (5/8-11-THD)2
8T41218 WASHER-HARD (11X21X2.5-MM THK)10
8T42239 WASHER-HARD (13.5X25.5X3-MM THK)4
9X825710 WASHER (17.5X30X3.5-MM THK)6
303478811 WASHER (0.34X0.69X0.09-IN THK)6
437765312 WASHER (16.7X71.4X4.5-MM THK)2
298736813 WASHER (0.66X1.31X0.095-IN THK)2
389344114 BRACKET AS1
437765615 MOUNT2
389355216 BRACKET AS-FUEL FILTER1
