System And Components
484-2920 WIRING GP-ENGINE & XMSNS/N MLJ1-UP
Group No: 484-2920
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7357 | 1 BOLT (M6X1X25-MM) | 6 | |
| 8T4138 | 2 BOLT (M6X1X20-MM) | 4 | |
| 7X2534 | 3 BOLT (M6X1X50-MM) | 2 | |
| 8T6912 | 4 BOLT (M8X1.25X50-MM) | 2 | |
| 8T6869 | 5 BOLT (M8X1.25X60-MM) | 2 | |
| 8T4970 | 6 BOLT (M6X1X14-MM) | 2 | |
| 7X2620 | 7 BOLT (M8X1.25X10-MM) | 4 | |
| 8T4189 | 8 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4137 | 10 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4179 | 11 BOLT (M12X1.75X20-MM) | 6 | |
| 8T4192 | 12 BOLT (M12X1.75X25-MM) | 1 | |
| 2143967 | 13 BOLT (M6X1X16-MM) | 2 | |
| 5C2890 | 14 NUT (M6X1-THD) | 2 | |
| 5C7261 | 15 NUT (M8X1.25-THD) | 2 | |
| 8T0389 | 16 LOCKNUT (M10X1.5-THD) | 5 | |
| 4842921 | 17 SCREW-BUTTON HEAD | 2 | |
| 4552256 | 18 BOLT-SOCKET HEAD (M5X0.8X20-MM) | 4 | |
| 3093996 | 19 WASHER (5.3X12.5X5-MM THK) | 4 | |
| 8T4205 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 18 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 14 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 3042604 | 24 WASHER (3.1X6.2X0.8-IN THK) | 4 | |
| 4641258 | 26 CLIP | 2 | |
| 3237231 | 27 TIE-CABLE | 2 | |
| 3S2093 | 29 STRAP-CABLE | 18 | |
| 4P7428 | 31 CLIP (LADDER) | 5 | |
| 3893479 | 32 SWITCH-TEMPERATURE (ENGINE TEMPERATURE) | 1 | |
| 4811051 | 33 FUSE AS (POWER MODULE) | 2 | |
| 3396361 | FUSE (40-AMPERE) | 2 | |
| 2750553 | 34 BAR-BUS | 1 | |
| 3982026 | 35 TIE-CABLE | 2 | |
| 4553027 | 36 TIE-CABLE | 4 | |
| 4749852 | 37 CONTROL GP-ELECTRONIC (FRONT FRAME) | 1 | |
| 4749855 | 38 CONTROL GP-ELECTRONIC (REAR FRAME) | 1 | |
| 4749674 | 39 CONTROL GP-ELECTRONIC (POWER DISTRIBUTION) | 1 | |
| 4738975 | 40 MOUNT | 3 | |
| 5126087 | 41 PLATE AS | 1 | |
| 4749677 | 42 CABLE | 1 | |
| 4749678 | 43 CABLE | 1 | |
| 5027633 | 44 CABLE | 1 | |
| 4749681 | 45 CABLE | 1 | |
| 4842910 | 46 CABLE | 1 | |
| 4842923 | 47 BRACKET AS | 1 | |
| 4811052 | 48 MOUNT | 4 | |
| 4842924 | 49 HARNESS AS-ENGINE | 1 | |
| 4811056 | 50 FUSE AS (POWER MODULE) | 2 | |
| 3396363 | FUSE (60-AMPERE) | 1 | |
| 4817718 | 51 BRACKET AS | 1 | |
| 4813376 | 52 CABLE | 1 | |
| 4842911 | 53 CABLE | 1 | |
| 4842912 | 54 CABLE | 1 | |
| 4811057 | 55 FILM-INFORMATION (FUSE) | 1 | |
| 4842925 | 56 BRACKET AS | 2 | |
| 8T4908 | 57 BOLT (M8X1.25X25-MM) | 1 | |
| 7K1181 | 58 STRAP-CABLE | 2 | |
| 3099184 | 59 LOCKNUT (M8X1.25-THD) | 1 | |
| 2990370 | 60 TRIM (1-FT) | ||
| 5052227 | 61 CLIP | 6 | |
| 5002293 | 62 CLIP (LADDER) | 1 | |
| 5C9553 | 63 BOLT (M6X1X16-MM) | 2 | |
| 3751424 | 64 PLUG-GLOW | 1 |
