System And Components
289-2515 COMBUSTION GP-EXHAUSTS/N LEE3641-UP
Group No: 289-2515
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 2041611 | 2 STRAP-CABLE (DUAL) | 1 | |
| 2856393 | 3 CLIP (LADDER) | 1 | |
| 2886818 | 4 SENSOR-TEMPERATURE (EXHAUST) | 1 | |
| 2890728 | 5 NUT (M8X1.25-THD) | 2 | |
| 2893107 | 6 GASKET | 1 | |
| 2902102 | 7 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2903930 | 8 BOLT (M8X1.25X55-MM) | 2 | |
| 2911588 | 9 TUBE AS | 1 | |
| 2916641 | 10 CLIP | 1 | |
| 2953099 | 11 SPARK PLUG (AFTERTREATMENT REGEN DEVICE) | 1 | |
| 3003741 | 12 COMBUSTION GP-EXHAUST | 1 | |
| 3008688 | 13 CLAMP-BAND | 1 | |
| 3112976 | 14 SUPPORT AS | 1 | |
| 3131449 | 15 SENSOR-TEMPERATURE (FLAME DETECT, TURBO OUTLET)(EXHAUST) | 1 | |
| 1325789 | 16 CLIP (LADDER) | 1 | |
| 2901993 | 17 STRAP-CABLE | 1 | |
| 2956235 | 18 WIRE AS-IGNITION | 1 | |
| 3E4352 | 19 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 6V3940 | 20 BOLT (M8X1.25X25-MM) | 4 | |
| 6V5215 | 21 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5217 | 22 BOLT (M8X1.25X20-MM) | 2 | |
| 6V7728 | 23 BOLT (M6X1X45-MM) | 1 | |
| 6V8490 | 24 BOLT (M6X1X25-MM) | 1 | |
| 7X2619 | 25 BOLT (M6X1X10-MM) | 1 | |
| 9M1974 | 26 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 9N0869 | 27 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 3 |
